MX-J570V/MX-J680V
3-16
Item
Parts number Parts name Area
Remarks
A
R 777 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 778 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 784 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 785 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 786 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 787 QRE141J-103Y C RESISTOR 10K 5% 1/4W
RY 1 QSK0109-001 RELAY
R1021 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1022 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1031 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1032 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1033 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R1034 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1035 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1036 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R1037 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1038 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1039 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1040 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1041 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1042 QRE141J-221Y C RESISTOR 220 5% 1/4W
R1043 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1044 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R1045 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1061 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1062 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R1063 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1064 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1065 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1066 QRE141J-475Y C RESISTOR 4.7M 5% 1/4W
R1067 QRE141J-560Y C RESISTOR 56 5% 1/4W
R1068 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1069 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1070 QRE141J-561Y C RESISTOR 560 5% 1/4W
R1071 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1072 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1073 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1074 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
S 500 QSW0812-001 PUSH SWITCH
SP210 E3400-431 SPACER
SP431 VYSA1R4-058 SPACER
SP434 E3400-431 SPACER
TB101 QNZ0079-001Z TAB
TB102 QNZ0079-001Z TAB
VR901 QVQ0045-B54 V RESISTOR
Electrical parts list (Power supplly&input/output board)
Block No. 01
A
