MX-J570V/MX-J680V
3-15
Item
Parts number Parts name Area
Electrical parts list (Power supplly&input/output board)
Remarks
Block No. 01
A
R 218 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 233 QRK126J-470X C RESISTOR
A
47 5% 1/2W
R 234 QRK126J-470X C RESISTOR
A
47 5% 1/2W
R 242 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 246 QRK126J-1R0X C RESISTOR
A
1.0 5% 1/2W
R 247 QRK126J-1R0X C RESISTOR
A
1.0 5% 1/2W
R 401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 402 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 403 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 404 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 405 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 406 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 407 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 408 QRE141J-5R6Y C RESISTOR 5.6 5% 1/4W
R 411 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 412 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 413 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 414 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 426 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 431 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 432 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 434 QRJ146J-4R7X UNF C.RESISTOR
A
4.7 5% 1/4W
R 435 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 436 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 437 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 438 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 439 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 440 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 441 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 442 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 466 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 467 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 468 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 469 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 470 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 471 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 472 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 473 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 474 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R 475 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 496 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 526 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 527 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 528 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 529 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 530 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 533 QRE141J-204Y C RESISTOR 200K 5% 1/4W
R 534 QRE141J-204Y C RESISTOR 200K 5% 1/4W
R 535 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 536 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 537 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 551 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 552 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 553 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 554 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 561 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 562 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 581 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 582 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 583 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 584 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 585 QRE141J-242Y C RESISTOR 2.4K 5% 1/4W
R 586 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 588 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 589 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 590 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 593 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 594 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 595 QRE141J-433Y C RESISTOR 43K 5% 1/4W
R 596 QRE141J-433Y C RESISTOR 43K 5% 1/4W
R 597 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 598 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 701 QRJ146J-470X UNF C.RESISTOR 47 5% 1/4W
R 702 QRJ146J-470X UNF C.RESISTOR 47 5% 1/4W
R 703 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 704 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 705 QRJ146J-821X UNF C.RESISTOR 820 5% 1/4W
R 706 QRJ146J-821X UNF C.RESISTOR 820 5% 1/4W
R 707 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 708 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 713 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 714 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 715 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 716 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 717 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 718 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 719 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 720 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 721 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 722 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 723 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 724 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 725 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 726 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 727 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 728 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 729 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 730 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 731 QRJ146J-4R7X UNF C.RESISTOR
A
4.7 5% 1/4W
R 732 QRJ146J-4R7X UNF C.RESISTOR
A
4.7 5% 1/4W
R 733 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 734 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 735 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 736 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 739 QRL01DJ-821X OMF RESISTOR 820 5% 1/1W
R 740 QRL01DJ-821X OMF RESISTOR 820 5% 1/1W
R 742 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 743 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 744 QRE141J-475Y C RESISTOR 4.7M 5% 1/4W
R 745 QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R 746 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 747 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 748 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 750 QRJ146J-470X UNF C.RESISTOR 47 5% 1/4W
R 753 QRZ0196-R22 EMIT.RESISTOR 1/1W
R 754 QRZ0196-R22 EMIT.RESISTOR 1/1W
R 761 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 762 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 766 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 767 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 768 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 774 QRJ146J-100X UNF.C RESISTOR
A
10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 776 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
A
Item
Parts number Parts name Area
Remarks
A
