MX-J800/MX-J850R
10
Item Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty Description
Block No. M4MM
1 VKS1165-00H CHASSIS B.ASS'Y 2
2 VKH5786-002 SHAFT 2
3 VKS5603-00D MAIN PULLEY ASY 2
4 VKS3785-001MM FR ARM 2
5 VKW5284-002 SWING SPRING 2
6 VKS2278-003 TRIGGER ARM 2
7 VKW5301-001 FR SPRING 2
8 VKW5266-001 ELEVATOR SPRING 2
9 WDL214025 WASHER 2
10 VKF3205-00B F.WHEEL ASSY(R) 2
11 WDL183425 SLIT WASHER 2
12 VKF3207-00B F.WHEEL ASSY(L) 2
13 WDL173525-6 SLIT WASHER 2
14 VKZ3174-00A DC SOLENOID 2
15 VKB3000-182 CAPSTAN BELT(B) 2
16 MSI-5U2LWA D.C.MOTOR ASS'Y 1
17 VKR4761-001 MOTOR PULLEY 1
18 QYSPSP2604Z SCREW 2
19 VKM3907-001 JOINT BRACKET 1
20 QYSBSF2608Z T.SCREW 6
21 LV41090-001A P.B.HEAD 1
22 LV41089-001A R/P&E HEAD 1
23 VKW5302-001 HEAD SPRING 2
24 VKZ4730-001 SPECIAL SCREW 4
25 VKS2279-00D HEAD MOUNT ASSY 1
26 VKW5299-002 PIN ROL.SP.(R) 2
27 VKS2277-005 DIRECTION LEVER 2
28 VKP4233-00A PINCH ROL. ASSY 4
29 VKW5285-001 RETURN SPRING 2
30 VKS3786-00G CLUTCH ASS'Y 2
31 VKS2275-00D HEAD MOUNT ASSY 1
32 VKW5300-002 PIN ROL.SP.(L) 2
33 VKS1167-001 HEAD MOUNT BASE 2
34 VKS2274-002 REEL GEAR 4
35 VKM3906-003 PLAY SW LEVER 2
36 VKW5286-002 B.T. SPRING 4
37 VKS5559-001 PLAY IDLE GEAR 2
38 VKY3149-002 CASSETTE SP. 2
39 VKW5279-001 HEAD BASE SP(R) 2
40 VKW5280-001 HEAD BASE SP(L) 2
41 VKW5296-001 EARTH SPRING 2
42 VKS5597-00A BLIND 2
43 VKS1166-003 CONTROL CAM 2
45 QYSBSF2608Z T.SCREW 5
FOR P.W.B.
46 VKR4749-002 IDLE PULLEY 2
47 QYSBSF2006Z SCREW 2
To Next Page
