MX-J800/MX-J850R

Item

Parts number Parts name Area

Electrical parts list (Power AMP board)

Remarks

Block No. 01

C 201 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 202 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 203 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 204 QEZ0461-478 E CAPACITOR

4700MF

C 205 QEZ0461-478 E CAPACITOR

4700MF

C 211 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 212 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 213 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 214 QETM1VM-228 E CAPACITOR

2200MF 20% 35V

C 215 QETM1VM-228 E CAPACITOR

2200MF 20% 35V

C 216 QETN1VM-107Z E CAPACITOR 100MF 20% 35V

C 217 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 218 EETC1HM-226ZJC E CAPACITOR

C 219 QDYB1CM-103Y C CAPACITOR

C 220 EETC1HM-226ZJC E CAPACITOR

C 221 EETC1HM-475ZJC E CAPACITOR

C 222 EETC1HM-475ZJC E CAPACITOR

C 223 EETC1HM-105ZJC E CAPACITOR

C 224 EETC1HM-105ZJC E CAPACITOR

C 233 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 238 QFLM1HJ-223Z M CAPACITOR C.022MF 5% 50V

C 238 QFLM1HJ-223Z M CAPACITOR B,E,EN,EV.022MF 5% 50V

C 239 QFLM1HJ-223Z M CAPACITOR B,E,EN,EV.022MF 5% 50V

C 239 QFLM1HJ-223Z M CAPACITOR C.022MF 5% 50V

C 253 QETM1EM-338 E CAPACITOR 3300MF 20% 25V

C 360 EETC1EM-226ZJC E CAPACITOR

C 361 QCF11HZ-103 C CAPACITOR .010MF +80:-20%

C 362 EETC1EM-226ZJC E CAPACITOR

C 366 EETC1EM-226ZJC E CAPACITOR

C 367 QCF11HZ-103 C CAPACITOR .010MF +80:-20%

C 368 EETC1EM-226ZJC E CAPACITOR

C 369 EETC1EM-226ZJC E CAPACITOR

C 370 QCF11HZ-103 C CAPACITOR .010MF +80:-20%

C 371 EETC1EM-226ZJC E CAPACITOR

C 372 EETC1EM-226ZJC E CAPACITOR

C 373 QCF11HZ-103 C CAPACITOR .010MF +80:-20%

C 374 EETC1EM-226ZJC E CAPACITOR

C 703 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V

C 704 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V

C 705 QCS11HJ-220 C CAPACITOR 22PF 5% 50V

C 706 QCS11HJ-220 C CAPACITOR 22PF 5% 50V

C 707 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 708 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 709 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 710 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 711 QETN1JM-476Z E CAPACITOR 100MF 20% 50V

C 712 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 713 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 713 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 714 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 714 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 715 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 715 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 716 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 716 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 717 QFLM1HJ-473Z M CAPACITOR J.047MF 5% 50V

C 718 QFLM1HJ-473Z M CAPACITOR J.047MF 5% 50V

C 721 QTE1V06-106Z E CAPACITOR

C 722 QTE1V06-106Z E CAPACITOR

C 723 QFVJ1HJ-474Z CAPACITOR .47MF 5% 50V

C 726 EETC1EM-106ZJC E.CAPACITOR

C 729 EETC1CM-476ZJC E.CAPACITOR

C 739 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 781 EETC1HM-225ZJC E CAPACITOR

C 782 EETC1HM-225ZJC E CAPACITOR

C 783 QCBB1HK-471Y C CAPACITOR B,E,EN,EV470PF 10% 50V

C 783 QCBB1HK-101Y C CAPACITOR J,C100PF 10% 50V

C 784 QCBB1HK-101Y C CAPACITOR J,C100PF 10% 50V

C 784 QCBB1HK-471Y C CAPACITOR B,E,EN,EV470PF 10% 50V

C 785 QCBB1HK-181Y C CAPACITOR 180PF 10% 50V

C 786 QCBB1HK-181Y C CAPACITOR 180PF 10% 50V

C 787 EETC1EM-476ZJC E CAPACITOR

C 788 EETC1EM-476ZJC E CAPACITOR

C 789 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 790 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 791 EETC1HM-226ZJC E CAPACITOR

C 792 EETC1HM-226ZJC E CAPACITOR

C 793 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 793 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 794 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 794 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 795 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 795 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 796 QFVJ1HJ-104Z TF CAPACITOR B,E,EN,EV.10MF 5% 50V

C 796 QFVJ1HJ-104Z TF CAPACITOR C.10MF 5% 50V

C 797 QFLM1HJ-473Z M CAPACITOR J.047MF 5% 50V

C 798 QFLM1HJ-473Z M CAPACITOR J.047MF 5% 50V

C 799 QDYB1CM-103Y C CAPACITOR J,C

C 799 QFLM1HJ-103Z C CAPACITOR B,E,EN,EV.010MF 5% 50V

CN102 QGB2510J1-10 CONNECTOR

CN103 QGB2501J1-11 B TO B CONNE

CN104 QGB2501J1-06 B TO B CONNE

CN105 QGB2510J1-11 CONNECTOR

CN106 QGB2501K2-10 B TO B CONNE

CN107 QGB2501K2-07 B TO B CONNE

CN109 QGA3901C1-05 5P CONNECTOR

CN111 QGD2501C1-04Z SOCKET

CN112 QGB2510K2-10 CONNECTOR

CN113 QGB2501K2-11 B TO B CONNE TO FMH-001-2

CN114 QGB2501K2-06 B TO B CONNE TO FMH-001-2

CN119 EWS285-202V SKT WIRE

CN120 QGA2501C4-03 CONNECTOR

CN703 QGB2510K2-06 CONNECTOR TO CONN. BOARD

CN704 QGB2510K2-05 CONNECTOR TO CONN. BOARD

CN713 QGB2510J1-06 CONNECTOR

CN714 QGB2510J1-05 CONNECTOR

CN915 QGD2501C1-04Z SOCKET FOR H/PHONE FW

D 201 1N5402M-20 DIODE

D 202 1N5402M-20 DIODE

D 203 1N5402M-20 DIODE

D 204 1N5402M-20 DIODE

D 211 30DF2-FC DIODE

D 212 30DF2-FC DIODE

D 213 30DF2-FC DIODE

D 214 30DF2-FC DIODE

D 217 1SR35-400A-T5 DIODE

D 218 1SR35-400A-T5 DIODE

D 219 MTZJ33C-T2 Z DIODE

D 220 MTZJ9.1C-T2 Z DIODE

D 221 MTZJ5.1B-T2 ZENER DIODE

D 223 1SS133-T2 SI DIODE

D 224 1SS133-T2 SI DIODE

D 225 1SS133-T2 SI DIODE

D 227 1SR35-400A-T5 DIODE

D 231 RN1Z-F1 SI DIODE

D 232 RN1Z-F1 SI DIODE

Item

Parts number Parts name Area

Remarks
