MX-J800/MX-J850R
15
Item
Parts number Parts name Area
Remarks
A
D 233 RN1Z-F1 SI DIODE
A
D 234 RN1Z-F1 SI DIODE
A
D 245 1SS133-T2 SI DIODE
D 360 MTZJ5.1B-T2 ZENER DIODE
D 361 MTZJ11C-T2 Z DIODE
D 362 MTZJ6.8C-T2 Z DIODE
D 365 MTZJ9.1B-T2 ZENER DIODE
D 366 MTZJ11C-T2 ZENER DIODE
D 367 MTZJ10C-T2 Z.DIODE
D 368 MTZJ11C-T2 Z.DIODE
D 369 MTZJ10C-T2 Z.DIODE
D 370 MTZJ11C-T2 Z.DIODE SHORT TEST
D 703 MTZJ8.2C-T2 ZENER DIODE
D 704 MTZJ8.2C-T2 ZENER DIODE
D 719 1SS133-T2 SI DIODE
D 720 1SS133-T2 SI DIODE
D 721 MTZJ8.2C-T2 ZENER DIODE
D 722 MTZJ8.2C-T2 ZENER DIODE
D 723 MTZJ33C-T2 Z DIODE
D 724 MTZJ33C-T2 Z DIODE
D 728 1SS133-T2 SI DIODE
D 789 1SS133-T2 SI DIODE
D 790 1SS133-T2 SI DIODE
EP201 E409182-001SM GRAND TERMINAL
FT111 QNG0020-001Z FUSE CLIP
FT112 QNG0020-001Z FUSE CLIP
FT511 QNG0020-001Z FUSE CLIP
FT512 QNG0020-001Z FUSE CLIP
FT521 QNG0020-001Z FUSE CLIP
FT522 QNG0020-001Z FUSE CLIP
FW101 QUM134-12DGZ4 FLAT WIRE
FW411 QUM137-13DGZ4 FLAT WIRE
IC701 STK411-210E IC
IC781 TDA7295 IC
IC782 TDA7295 IC
L 201 QQR0779-001Z INDUCTOR B,E,EN,EV
L 201 QQR0779-001Z INDUCTOR C
L 701 QQLZ005-R45 INDUCTOR
L 702 QQLZ005-R45 INDUCTOR
L 781 QQLZ005-R45 INDUCTOR
L 782 QQLZ005-R45 INDUCTOR
Q
201 2SB1274/RS/ TRANSISTOR
Q
203 KRC107M-T D.TRANSISTOR
Q
204 KRC107M-T D.TRANSISTOR
Q
205 KRC107M-T D.TRANSISTOR
Q
240 KTC3199/GL/-T TRANSISTOR
Q
241 KTC3199/GL/-T TRANSISTOR
Q
242 KTC3199/GL/-T TRANSISTOR
Q
360 2SD2394/EF/ TRANSISTOR B,E,EN,EV
Q
360 2SD2061/EF/ TRANSISTOR J,C
A
Q
361 KTC3199/GL/-T TRANSISTOR
Q
362 KTC3199/GL/-T TRANSISTOR
Q
365 2SD2394/EF/ TRANSISTOR B,E,EN,EV
A
Q
365 2SD2061/EF/ SI.TRANSISTOR J,C
A
Q
366 2SD2061/EF/ SI.TRANSISTOR J,C
A
Q
366 2SD2394/EF/ TRANSISTOR B,E,EN,EV
A
Q
367 KTA1267/YG/-T TRANSISTOR
Q
368 KTC3199/GL/-T TRANSISTOR
Q
369 2SD2394/EF/ TRANSISTOR B,E,EN,EV
A
Q
369 2SD2061/EF/ SI.TRANSISTOR J,C
A
Q
370 KTC3199/GL/-T TRANSISTOR
Q
371 2SB1565/EF/ TRANSISTOR
A
Q
373 KRA104M-T D.TRANSISTOR
Q
374 KRC104M-T D.TRANSISTOR
Q
375 KRC104M-T D.TRANSISTOR
Q
376 KRA104M-T D.TRANSISTOR
Q
701 2SA1038S/SE/-T TRANSISTOR
Q
702 2SA1038S/SE/-T TRANSISTOR
Q
726 2SC2389S/SE/-T TRANSISTOR
Q
727 2SA1038S/SE/-T TRANSISTOR
Q
728 KTC3199/GL/-T TRANSISTOR
Q
733 2SC3576-JVC-T TRANSISTOR
Q
734 2SC3576-JVC-T TRANSISTOR
Q
735 2SC3576-JVC-T TRANSISTOR
Q
736 2SC3576-JVC-T TRANSISTOR
Q
737 KRA111M-T D.TRANSISTOR
Q
758 2SA1038S/S/-T TRANSISTOR
Q
781 2SA1038S/SE/-T TRANSISTOR
Q
782 2SA1038S/SE/-T TRANSISTOR
R 202 QRJ146J-4R7X UNF C.RESISTOR J
A
4.7 5% 1/4W
R 203 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 204 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 205 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 209 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 210 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 211 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R 215 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 216 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 238 QRJ146J-4R7X UNF C.RESISTOR C4.7 5% 1/4W
R 238 QRJ146J-4R7X UNF C.RESISTOR B,E,EN,EV4.7 5% 1/4W
R 239 QRJ146J-4R7X UNF C.RESISTOR B,E,EN,EV4.7 5% 1/4W
R 239 QRJ146J-4R7X UNF C.RESISTOR C4.7 5% 1/4W
R 242 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 245 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 246 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 247 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 290 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 291 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 292 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 293 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 294 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 295 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 296 QRT01DJ-R22X UNF.MF.RESISTOR 5% 1/1W
R 299 QRL012J-332 UNF.OMF.RES. 3.3K 5% 1/1W
R 360 QRZ9042-2R2X F RESISTOR C
A
2.2 1/0W
R 360 QRZ9042-2R2X F RESISTOR B,E,EN,EV
A
2.2 1/0W
R 361 QRZ9006-4R7X F RESISTOR B,E,EN,EV
A
4.7 1/0W
R 361 QRZ9042-2R2X F RESISTOR C
A
2.2 1/0W
R 362 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 363 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 364 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 365 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 366 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 367 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 368 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 371 QRE141J-4R7Y C RESISTOR 4.7 5% 1/4W
R 372 QRE141J-4R7Y C RESISTOR 4.7 5% 1/4W
R 373 QRZ9021-220 FUSI RESISTOR C
A
22 1/0W
R 373 QRZ9021-220 FUSI.RESISTOR B,E,EN,EV
A
22 1/0W
R 374 QRZ9021-220 FUSI.RESISTOR B,E,EN,EV
A
22 1/0W
R 374 QRZ9021-220 FUSI RESISTOR C
A
22 1/0W
R 374 QRL022J-220 O.M.F.RESISTOR J
A
22 5% 1/2W
R 375 QRZ9021-220 FUSI.RESISTOR B,E,EN,EV
A
22 1/0W
R 375 QRZ9021-220 FUSI.RESISTOR C
A
22 1/0W
R 375 QRL022J-220 UNF.OMF.RES. J
A
22 5% 1/2W
R 376 QRE141J-221Y C RESISTOR 220 5% 1/4W
Electrical parts list (Power AMP board)
Block No. 01
Item
Parts number Parts name Area
Remarks
A
