JVC MX-J800 User Manual

MX-J800/MX-J850R
16
Item
Parts number Parts name Area
Remarks
A
R 377 QRE141J-681Y C RESISTOR 680 5% 1/4W
R 378 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R 379 QRL022J-220 UNF.OMF.RES. J22 5% 1/2W
R 380 QRL022J-220 UNF.OMF.RES. J22 5% 1/2W
R 381 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 382 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 383 QRL01DJ-150X OMF RESISTOR J
A
15 5% 1/1W
R 384 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 385 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 388 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 389 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 390 QRL022J-220 UNF.OMF.RES. J22 5% 1/2W
R 391 QRL022J-220 UNF.OMF.RES. J22 5% 1/2W
R 701 QRL01DJ-101X OMF RESISTOR 100 5% 1/1W
R 702 QRL01DJ-101X OMF RESISTOR 100 5% 1/1W
R 703 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 704 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 705 QRJ146J-681X UNF C.RESISTOR 680 5% 1/4W
R 706 QRJ146J-681X UNF C.RESISTOR 680 5% 1/4W
R 707 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 708 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 709 QRT01DJ-R22X UNF.MF.RESISTOR 5% 1/1W
R 710 QRT01DJ-R22X UNF.MF.RESISTOR 5% 1/1W
R 711 QRT01DJ-R22X UNF.MF.RESISTOR 5% 1/1W
R 712 QRT01DJ-R22X UNF.MF.RESISTOR 5% 1/1W
R 713 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 714 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 715 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 716 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 717 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 718 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 719 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 720 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 721 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 722 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 723 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 724 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 725 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 726 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 727 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 728 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 729 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 730 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 733 QRE141J-472Y C RESISTOR 47K 5% 1/4W
R 734 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 735 QRE141J-472Y C RESISTOR 47K 5% 1/4W
R 736 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 739 QRL01DJ-821X OMF RESISTOR 820 5% 1/1W
R 740 QRL01DJ-821X OMF RESISTOR 820 5% 1/1W
R 741 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 742 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 743 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 744 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 745 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 746 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 747 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 748 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 749 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 750 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 751 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 752 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 766 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 767 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 771 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 772 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 774 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 776 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 783 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 784 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 785 QRJ146J-182X C RESISTOR 1.8K 5% 1/4W
R 786 QRJ146J-182X UNF C.RESISTOR 1.8K 5% 1/4W
R 787 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 788 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 789 QRT01DJ-R22X UNF.MF.RES.I.M 5% 1/1W
R 790 QRT01DJ-R22X UNF.MF.RES.I.M 5% 1/1W
R 791 QRT01DJ-R22X UNF.MF.RES.I.M 5% 1/1W
R 792 QRT01DJ-R22X UNF.MF.RES.I.M 5% 1/1W
R 793 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 794 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 795 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 796 QRJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R 797 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 798 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R1001 QRZ9044-335 C RESISTOR J,C3.3M 1/0W
SP200 E3400-439 FELT SPACER
TB101 QNZ0079-001Z TAB
TB102 QNZ0079-001Z TAB
TH202 QAD0095-4R7Z P.THERMISTOR B,E,EN,EV
TH202 QAD0095-4R7Z POSISTOR C
TW120 WJK0040-001A E-SI C WIRE C-B
Electrical parts list (Power AMP board)
