MX-J800/MX-J850R

Item

Parts number Parts name Area

Electrical parts list (Function,Tuner,Main board)

Remarks

Block No. 02

C 1 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V

C 3 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 4 QDYB1CM-103Y C CAPACITOR

C 5 QETN1AM-107Z E CAPACITOR B,E,EN,EV100MF 20% 10V

C 5 EETC1CM-476ZJC E CAPACITOR J,C

C 8 QCSB1HJ-150Y C CAPACITOR B,E,EN,EV15PF 5% 50V

C 9 QDXB1CM-272Y C CAPACITOR B,E,EN,EV

C 10 EETC1HM-474ZJC E CAPACITOR

C 12 QCSB1HJ-100Y C CAPACITOR J,C10PF 5% 50V

C 12 QCSB1HJ-150Y C CAPACITOR B,E,EN,EV15PF 5% 50V

C 13 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 14 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 15 QCBB1HK-391Y C CAPACITOR B,E,EN,EV390PF 10% 50V

C 18 QCBB1HK-471Y C CAPACITOR J,C470PF 10% 50V

C 18 QDXB1CM-152Y C CAPACITOR B,E,EN,EV

C 19 QCBB1HK-471Y C CAPACITOR J,C470PF 10% 50V

C 19 QDXB1CM-152Y C CAPACITOR B,E,EN,EV

C 20 EETC1HM-226ZJC E CAPACITOR

C 21 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 22 QFVJ1HJ-274Z CAPACITOR .27MF 5% 50V

C 23 EETC1HM-105ZJC E CAPACITOR

C 24 EETC1HM-226ZJC E CAPACITOR

C 25 QFLM1HJ-223Z C CAPACITOR B,E,EN,EV.022MF 5% 50V

C 25 QFLM1HJ-273Z C CAPACITOR J,C.027MF 5% 50V

C 26 EETC1EM-106ZJC E CAPACITOR

C 27 EETC1HM-105ZJC E CAPACITOR

C 28 EETC1HM-105ZJC E CAPACITOR

C 29 QFLM1HJ-182Z M CAPACITOR B,E,EN,EV1800PF 5% 50V

C 29 QFLM1HJ-222Z M CAPACITOR J,C2200PF 5% 50V

C 30 QFLM1HJ-222Z M CAPACITOR J,C2200PF 5% 50V

C 30 QFLM1HJ-182Z M CAPACITOR B,E,EN,EV1800PF 5% 50V

C 31 QCSB1HJ-330Y C CAPACITOR B,E,EN,EV33PF 5% 50V

C 31 QCSB1HJ-560Y C CAPACITOR J,C56PF 5% 50V

C 32 QDGB1HK-102Y C CAPACITOR

C 33 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 34 EETC1HM-474ZJC E CAPACITOR

C 35 QDYB1CM-103Y C CAPACITOR

C 36 EETC1HM-105ZJC E CAPACITOR

C 37 EETC1HM-474ZJC E CAPACITOR

C 38 EETC1HM-105ZJC E CAPACITOR

C 39 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V

C 40 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 41 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 42 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 43 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 44 QDGB1HK-102Y C CAPACITOR J,C

C 51 EETC1HM-105ZJC E CAPACITOR

C 52 EETC1HM-105ZJC E CAPACITOR

C 60 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V

C 61 QCSB1HJ-120Y C CAPACITOR 12PF 5% 50V

C 62 QCSB1HJ-120Y C CAPACITOR 12PF 5% 50V

C 63 QCBB1HK-473Y C CAPACITOR .047MF 10% 50V

C 65 QDGB1HK-102Y C CAPACITOR

C 66 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V

C 67 QCSB1HJ-270Y C CAPACITOR 27PF 5% 50V

C 68 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 69 QFVJ1HJ-105Z TF.CAPACITOR 1.0MF 5% 50V

C 70 QDXB1CM-392Y C CAPACITOR

C 71 EETC1CM-476ZJC E CAPACITOR

C 72 QDGB1HK-102Y C CAPACITOR

C 80 QCBB1HK-820Y C CAPACITOR B,E,EN,EV82PF 10% 50V

C 81 QCSB1HJ-470Y C CAPACITOR B,E,EN,EV47PF 5% 50V

C 82 EETC1CM-106ZJC E CAPACITOR B,E,EN,EV

C 83 QCBB1HK-473Y C CAPACITOR B,E,EN,EV.047MF 10% 50V

C 84 EETC1HM-225ZJC E CAPACITOR B,E,EN,EV

C 85 QCBB1HK-331Y C CAPACITOR B,E,EN,EV330PF 10% 50V

C 86 QCBB1HK-561Y C CAPACITOR B,E,EN,EV560PF 10% 50V

C 89 QDGB1HK-102Y C CAPACITOR B,E,EN,EV

C 90 QDYB1CM-103Y C CAPACITOR B,E,EN,EV

C 98 QCSB1HJ-100Y C CAPACITOR B,E,EN,EV10PF 5% 50V

C 360 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 361 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 365 QETN1CM-227Z E CAPACITOR 220MF 20% 16V

C 366 QETN1AM-108Z E CAPACITOR 1000MF 20% 10V

C 372 EETC1HM-475ZJC E CAPACITOR

C 373 QDYB1CM-103Y C CAPACITOR

C 380 EETC1HM-224ZJC E CAPACITOR

C 381 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%

C 382 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%

C 383 EETC1EM-476ZJC E CAPACITOR

C 385 EETC1HM-105ZJC E CAPACITOR

C 386 QDGB1HK-681Y C CAPACITOR

C 387 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V

C 388 QDXB1CM-182Y C CAPACITOR

C 389 QCS11HJ-330 C CAPACITOR 33PF 5% 50V

C 390 EETC1HM-224ZJC E CAPACITOR

C 398 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 399 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 401 QFLM1HJ-222Z M CAPACITOR

2200PF 5% 50V

C 402 QFLM1HJ-222Z M CAPACITOR

2200PF 5% 50V

C 403 QFLM1HJ-102Z M CAPACITOR 1000PF 5% 50V

C 404 QFLM1HJ-102Z M CAPACITOR 1000PF 5% 50V

C 407 QTE1V06-106Z E CAPACITOR

C 408 QTE1V06-106Z E CAPACITOR

C 411 EETC1EM-106ZJC E CAPACITOR

C 412 EETC1EM-106ZJC E CAPACITOR

C 413 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 414 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 415 EETC1EM-106ZJC E CAPACITOR

C 416 EETC1EM-106ZJC E CAPACITOR

C 417 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 418 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 419 EETC1EM-106ZJC E CAPACITOR

C 420 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 421 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 422 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 423 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 424 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 425 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 426 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 427 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 428 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 429 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 430 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 431 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 432 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 433 QTE1H39-225Z E CAPACITOR

C 434 QTE1H39-225Z E CAPACITOR

C 435 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 436 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 445 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 446 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 447 QTE1C39-106Z E CAPACITOR

C 448 QTE1C39-106Z E CAPACITOR

C 453 QCBB1HK-101Y C CAPACITOR B,E,EN,EV100PF 10% 50V

C 455 QCBB1HK-101Y C CAPACITOR B,E,EN,EV100PF 10% 50V

Item

Parts number Parts name Area

Remarks
