MX-J800/MX-J850R
5
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
91 QUQ110-1916BJ FFC WIRE(FC410) 1
CD TO FMC
92 QUQ412-2112CJ FFC WIRE(FC801) 1
FMB(FL)TO FMB(C)
93 QUQ412-2308CJ FFC WIRE(FC802) 1
FMB(FL)TO FMB(C)
94 GV10013-060A REAR PANEL
B,E,EN,EV
1
CA-MXJ850R
GV10013-058A REAR PANEL
C
1
MX-J800
GV10013-057A REAR PANEL
J
1
MX-J800
95 E207356-002SM REAR COVER 1
96 QYSBSG3008Z T.SCREW 2
C3 & STAY BRACKET
97 QYSBSGY3008E SPECIAL SCREW 1
AUX/REAR PANEL
98 QYSBSGY3008E SPECIAL SCREW 1
E.PLATE/R.PANEL
99 QYSBSGY3008E SPECIAL SCREW 1
R.PANEL/ C.BASE
100 QYSBSGY3008E SPECIAL SCREW 4
H.SINK/ R.PANEL
101 QYSBSGY3008E SPECIAL SCREW 2
C3 / REAR PANEL
102 QYSBSGY3008E SPECIAL SCREW 2
SPK.TEM./R.PANE
103 QYSBSGY3008E SPECIAL SCREW 2
ANTENA/ R.PANEL
104 QYSBSGY3008E SPECIAL SCREW 2
R.COVER/R.PANEL
106 QYSBSGY3008E SPECIAL SCREW 1
GROUND/R.PANEL
107 QYSBSGY3008E SPECIAL SCREW 1
SUBWOOFER/R.PANEL
108 QYSBSGY3008E SPECIAL SCREW 1
OPTICAL/R.PANEL
109 GV10012-001A/S/ METAL COVER 1
110 QYSDSG3006M T.SCREW 2
M.COVER+C.BASE
111 QYSBSGY3008E SPECIAL SCREW 6
M.COVER+R.PANEL
112 GV30033-006A CD FITTING 1
DISC 1
113 GV30034-004A CD FITTING 1
DISC 2
114 GV30035-006A CD FITTING 1
DISC 3
115 GV30028-004A VOLUMA KNOB 1
116 GV20026-017A WINDOW SCREEN 1
MX-J800
GV20026-018A WINDOW SCREEN 1
CA-MXJ850R
120 GV40048-001A PROTECT SHEET(A) 1
121 GV40049-001A PROTECT SHEET(B)
J,C
1
122 FMYSH103-003 SPACER 1
STICK TO TRANSH
123 FMKL4007-001 BRACKET 1
124 FMPK4003-001T MICA SHEET 1
125 QYSBSGY3008E SPECIAL SCREW 1
PROLOGIC/R.PANE
126 GV30032-001A FL HOLDER 1
127 E3400-439 FELT SPACER 2
128 MXN-13FB12F DC MOTOR 1
129 GV40022-001A MOTOR PULLEY 1
130 GV30038-001A CAPSTAN BELT 1
131 FMYSH103-004 FELT SPACER 1
CA-MXJ850R
