Specifications
Amplifier section
Output Power: 100 W per channel, min. RMS, driven into
6
Ω
at 1 kHz with no more than 10% total
harmonic distortion.
Digital output:
OPTICAL DIGITAL OUTPUT:
–21 dBm to –15 dBm (660 nm ±30 nm)
Audio input sensitivity/Impedance
(Measured at 1 kHz, with tape recording signal 300 mV)
AUX: 300 mV/47 k
Ω
MIC 1/2: 3.0 mV/50 k
Ω
VIDEO OUT:
Color system:NTSC/PAL selectable
VIDEO (composite): 1 V(p-p)/75
Ω
S-VIDEO: Y (luminance) 1 V(p-p)/75
Ω
C (chrominance, burst)
0.286 V(p-p)/75
Ω
COMPONENT (Interlace/Progressive):
(Y) 1 V(p-p)/75
Ω
(P
B
/P
R
) 0.7 V(p-p)/75
Ω
Speaker Terminals: 6
Ω − 16 Ω
(Main speakers)
16
Ω − 32 Ω
(Surround speakers)
Others:
AV COMPU LINKx2 (
φ
3.5)
Tuner section
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range:
531 kHz – 1 602 kHz (at 9 kHz)
530 kHz – 1 600 kHz
(at 10 kHz)
Disc player section
Playable disc: DVD VIDEO/DVD AUDIO
CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/
Video CD/ Super Video CD/ MP3/ WMA/
JPEG format)
DVD-R/DVD-RW (recorded in video
format)
Dynamic range: 90 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
Cassette deck section
Frequency response
Normal (type I): 50 Hz – 14 000 Hz
Wow and flutter: 0.15 % (WRMS)
General
Power requirement: AC 110 V / AC 127 V / AC 220 V /
AC 230 V – AC 240 V ,
(adjustable with the voltage selector),
50 Hz / 60 Hz
Power consumption: 135 W (at operation)
17 W (on standby)
Dimensions (approx.):265 mm x 335 mm x 352 mm
(W/H/D)
Mass (approx.): 8.6 kg
Supplied Accessories
See page 3.
Speakers
Type: 3-Way 3-Speaker Bass Reflex Type
Speaker Systems: Woofer: 15 cm cone x 1
Mid: 5 cm cone x 1
Tweeter: 2 cm dome x 1
Power handling capacity: 100 W
Impedance: 6
Ω
Frequency range: 42 Hz – 37 000 Hz
Sound pressure level: 83 dB/W•m
Dimensions (approx.): 205 mm x 337 mm x 240 mm
(W/H/D)
Mass (approx.): 3.5 kg each
Design and specifications are subject to change without
notice.
