JVC MX-K10 - Page 106

 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
514 O R916 QRE141J-1R0 C RESISTOR 1
515 O R917 NRSA63J-102X MG RESISTOR 1K
516 ! O R951 RC3352 RESISTOR 3.3M
517 O RY301 8RL00071 RELAY G5PA-2
518 O RXX NIL NM
519 O TB901 201323010101 AC TERMINAL 1P
520 O TB902 201323010101 AC TERMINAL 1P
521 O FH951 201196010101 FUSE HOLDER 1P-5mm
522 O FH952 201196010101 FUSE HOLDER 1P-5mm
523 O SINK A 202323010101 SINK-AMP K30J/E T=1mm
524 O SCREW RT000611B3 SCREW 3xL8mm For sink to Q904
525 O SCREW RT000611B3 SCREW 3xL8mm For sink to Q907
---- ---- PWB 251100G01V THK1.6mm 94V0 PWB K30 COMB MAIN
