JVC MX-K10 - Page 105

 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
457 O R388 NRSA63J-222X MG RESISTOR 2.2K
458 O R389 NRSA63J-103X MG RESISTOR 10K
459 O R390 NRSA63J-561X MG RESISTOR 560
460 O R391 NRSA63J-222X MG RESISTOR 2.2K
461 O R401 NRSA63J-104X MG RESISTOR 100K
462 O R402 NRSA63J-682X MG RESISTOR 6.8K
463 O R404 NRSA63J-101X MG RESISTOR 100
464 O R405 NRSA63J-103X MG RESISTOR 10K
465 O R406 NRSA63J-682X MG RESISTOR 6.8K
466 O R407 NRSA63J-683X MG RESISTOR 68K
467 O R408 NIL NM
468 O R409 NRSA63J-154X MG RESISTOR 150K
469 O R410 NRSA63J-122X MG RESISTOR 1.2K
470 O R412 NRSA63J-182X MG RESISTOR 1.8K
471 O R413 NRSA63J-223X MG RESISTOR 22K
472 O R414 NRSA63J-472X MG RESISTOR 4.7K
473 O R415 NRSA63J-103X MG RESISTOR 10K
474 O R416 NRSA63J-682X MG RESISTOR 6.8K
475 O R417 NRSA63J-223X MG RESISTOR 22K
476 O R418 NRSA63J-222X MG RESISTOR 2.2K
477 O R421 NRSA63J-102X MG RESISTOR 1K
478 O R422 NRSA63J-102X MG RESISTOR 1K
479 O R423 NRSA63J-222X MG RESISTOR 2.2K
480 O R501 NRSA63J-104X MG RESISTOR 100K
481 O R502 NRSA63J-682X MG RESISTOR 6.8K
482 O R504 NRSA63J-101X MG RESISTOR 100
483 O R505 NRSA63J-103X MG RESISTOR 10K
484 O R506 NRSA63J-682X MG RESISTOR 6.8K
485 O R507 NRSA63J-683X MG RESISTOR 68K
486 O R508 NIL NM
487 O R509 NRSA63J-154X MG RESISTOR 150K
488 O R510 NRSA63J-122X MG RESISTOR 1.2K
489 O R512 NRSA63J-182X MG RESISTOR 1.8K
490 O R513 NRSA63J-223X MG RESISTOR 22K
491 O R514 NRSA63J-472X MG RESISTOR 4.7K
492 O R515 NRSA63J-103X MG RESISTOR 10K
493 O R516 NRSA63J-682X MG RESISTOR 6.8K
494 O R517 NRSA63J-223X MG RESISTOR 22K
495 O R518 NRSA63J-222X MG RESISTOR 2.2K
496 O R521 NRSA63J-102X MG RESISTOR 1K
497 O R522 NRSA63J-102X MG RESISTOR 1K
498 O R523 NRSA63J-222X MG RESISTOR 2.2K
499 O R901 NRSA63J-472X MG RESISTOR 4.7K
500 ! O R902 RF1010045N0000 FUSI RESISTOR 100 1/4W
501 O R903 NRSA63J-222X MG RESISTOR 2.2K
502 O R904 NRSA63J-101X MG RESISTOR 100
503 O R905 NRSA63J-101X MG RESISTOR 100
504 O R906 NRSA63J-103X MG RESISTOR 10K
505 O R907 NRSA63J-102X MG RESISTOR 1K
506 ! O R908 RF0220045N0000 FUSI RESISTOR 2.2 1/4W(RF)
507 O R909 NRSA63J-473X MG RESISTOR 47K
508 O R910 NRSA63J-223X MG RESISTOR 22K
509 O R911 NRSA63J-332X MG RESISTOR 3.3K
510 O R912 NRSA63J-471X MG RESISTOR 470
511 O R913 NRSA63J-471X MG RESISTOR 470
512 O R914 QRE141J-1R0 C RESISTOR 1
513 O R915 QRE141J-1R0 C RESISTOR 1
