 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
400 O R321 NRSA63J-222X MG RESISTOR 2.2K
401 O R322 NRSA63J-222X MG RESISTOR 2.2K
402 O R323 NRSA63J-222X MG RESISTOR 2.2K
403 O R324 NRSA63J-222X MG RESISTOR 2.2K
404 O R325 NRSA63J-222X MG RESISTOR 2.2K
405 O R327 NRSA63J-103X MG RESISTOR 10K
406 O R328 NRSA63J-103X MG RESISTOR 10K
407 O R329 NRSA63J-223X MG RESISTOR 22K
408 O R330 NRSA63J-473X MG RESISTOR 47K
409 O R331 NRSA63J-332X MG RESISTOR 3.3K
410 O R332 NRSA63J-472X MG RESISTOR 4.7K
411 O R333 NRSA63J-151X MG RESISTOR 150
412 O R334 NRSA63J-332X MG RESISTOR 3.3K
413 O R335 NRSA63J-472X MG RESISTOR 4.7K
414 O R336 NRSA63J-151X MG RESISTOR 150
415 O R337 NRSA63J-332X MG RESISTOR 3.3K
416 O R338 NRSA63J-102X MG RESISTOR 1K
417 O R339 NRSA63J-222X MG RESISTOR 2.2K
418 O R340 NRSA63J-222X MG RESISTOR 2.2K
419 O R341 NRSA63J-222X MG RESISTOR 2.2K
420 O R344 NRSA63J-102X MG RESISTOR 1K
421 O R345 NRSA63J-102X MG RESISTOR 1K
422 O R346 NRSA63J-470X MG RESISTOR 47
423 O R347 NRSA63J-102X MG RESISTOR 1K
424 O R348 NRSA63J-222X MG RESISTOR 2.2K
425 O R349 NRSA63J-221X MG RESISTOR 220
426 O R350 NRSA63J-102X MG RESISTOR 1K
427 O R351 NRSA63J-104X MG RESISTOR 100K
428 O R352 NRSA63J-153X MG RESISTOR 15K
429 O R353 NRSA63J-181X MG RESISTOR 180
430 O R354 NRSA63J-821X MG RESISTOR 820
431 O R355 NRSA63J-330X MG RESISTOR 33
432 O R356 NRSA63J-221X MG RESISTOR 220
433 O R357 NRSA63J-103X MG RESISTOR 10K
434 O R358 NRSA63J-104X MG RESISTOR 100K
435 O R359 NRSA63J-471X MG RESISTOR 470
436 O R361 NRSA63J-223X MG RESISTOR 22K
437 ! O R362 RF0220045N0000 FUSI RESISTOR 2.2-1/4W
438 O R363 NRSA63J-471X MG RESISTOR 470
439 O R364 NRSA63J-153X MG RESISTOR 15K
440 O R365 NRSA63J-332X MG RESISTOR 3.3K
441 O R366 NRSA63J-682X MG RESISTOR 6.8K
442 O R367 NRSA63J-103X MG RESISTOR 10K
443 O R368 NRSA63J-473X MG RESISTOR 47K
444 O R369 NRSA63J-473X MG RESISTOR 47K
445 O R370 NRSA63J-102X MG RESISTOR 1K
446 O R371 NRSA63J-223X MG RESISTOR 22K
447 O R372 NRSA63J-223X MG RESISTOR 22K
448 O R373 NRSA63J-222X MG RESISTOR 2.2K
449 O R374 NRSA63J-223X MG RESISTOR 22K
450 O R381 NRSA63J-104X MG RESISTOR 100K
451 O R382 NRSA63J-223X MG RESISTOR 22K
452 O R383 NRSA63J-473X MG RESISTOR 47K
453 O R384 NRSA63J-103X MG RESISTOR 10K
454 O R385 NRSA63J-104X MG RESISTOR 100K
455 O R386 QRE141J-100 C RESISTOR 10
456 O R387 NRSA63J-150X MG RESISTOR 15
3-39
