JVC MX-K10 - Page 103

 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
343 O R201 NRSA63J-393X MG RESISTOR 39K
344 O R202 NRSA63J-682X MG RESISTOR 6.8K
345 O R203 NRSA63J-222X MG RESISTOR 2.2K
346 O R204 NRSA63J-222X MG RESISTOR 2.2K
347 O R205 NRSA63J-154X MG RESISTOR 150K
348 O R206 NRSA63J-682X MG RESISTOR 5.6K
349 O R207 NRSA63J-0R0X MG RESISTOR 00
350 O R208 NRSA63J-103X MG RESISTOR 10K
351 O R209 NRSA63J-122X MG RESISTOR 1.2K
352 O R210 NRSA63J-222X MG RESISTOR 2.2K
353 O R211 NRSA63J-222X MG RESISTOR 2.2K
354 O R212 NRSA63J-562X MG RESISTOR 5.6K
355 O R213 NRSA63J-103X MG RESISTOR 10K
356 O R214 NRSA63J-102X MG RESISTOR 1K
357 O R215 NRSA63J-223X MG RESISTOR 22K
358 O R217 NRSA63J-222X MG RESISTOR 2.2K
359 O R218 NRSA63J-472X MG RESISTOR 4.7K
360 O R219 NRSA63J-103X MG RESISTOR 10K
361 O R220 NRSA63J-563X MG RESISTOR 56K
362 O R221 NRSA63J-152X MG RESISTOR 1.5K
363 O R223 NRSA63J-473X MG RESISTOR 47K
364 O R224 NRSA63J-152X MG RESISTOR 1.5K
365 O R225 QRM024K-R22 MP RESISTOR 0.22-2W
366 O R226 QRM024K-R22 MP RESISTOR 0.22-2W
367 ! O R227 RF1510045N0000 FUSI RESISTOR 150-1/4W
368 O R228 NRSA63J-220X MG RESISTOR 22
369 O R229 NRSA63J-220X MG RESISTOR 22
370 O R230 NRSA63J-220X MG RESISTOR 22
371 O R231 NRSA63J-103X MG RESISTOR 10K
372 ! O R232 RF3910045N0000 FUSI RESISTOR 390-1/4W
373 ! O R233 RF3910045N0000 FUSI RESISTOR 390-1/4W
374 O R234 NRSA63J-103X MG RESISTOR 10K
375 O R235 NRSA63J-103X MG RESISTOR 10K
376 O R236 NRSA63J-102X MG RESISTOR 1K
377 O R237 NRSA63J-104X MG RESISTOR 100K
378 O R238 NRSA63J-102X MG RESISTOR 1K
379 O R239 NRSA63J-103X MG RESISTOR 10K
380 O R250 NRSA63J-220X MG RESISTOR 22
381 O R251 NRSA63J-153X MG RESISTOR 15K
382 O R301 NRSA63J-102X MG RESISTOR 1K
383 O R303 NRSA63J-102X MG RESISTOR 1K
384 O R304 NRSA63J-331X MG RESISTOR 330
385 O R305 NRSA63J-103X MG RESISTOR 10K
386 O R306 NRSA63J-105X MG RESISTOR 1M
387 O R307 NRSA63J-222X MG RESISTOR 2.2K
388 O R308 NRSA63J-103X MG RESISTOR 10K
389 O R309 NRSA63J-100X MG RESISTOR 10
390 O R310 NRSA02J-390X MG RESISTOR 39
391 O R311 NRSA63J-100X MG RESISTOR 10
392 O R312 NRSA63J-102X MG RESISTOR 1K
393 O R313 NRSA63J-471X MG RESISTOR 470
394 O R314 NRSA63J-474X MG RESISTOR 470K
395 O R315 NRSA63J-222X MG RESISTOR 2.2K
396 O R316 NRSA63J-103X MG RESISTOR 10K
397 O R317 NRSA63J-472X MG RESISTOR 4.7K
398 O R319 NRSA63J-223X MG RESISTOR 22K
399 O R320 NRSA63J-473X MG RESISTOR 47K
3-38
