JVC MX-K10 - Page 102

 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
286 O Q405 2KTC3199GP0008 TRANSISTOR KTC3199
287 O Q501 2SD2144S/VW/-T TRANSISTOR 2SD2144S
288 O Q502 2SD2144S/VW/-T TRANSISTOR 2SD2144
289 O Q503 2KTC3199GP0008 TRANSISTOR KTC3199
290 O Q504 2KTC3199GP0008 TRANSISTOR KTC3199
291 O Q505 2KTC3199GP0008 TRANSISTOR KTC3199
292 O Q901 2SA934RP0007 TRANSISTOR 2SA934
293 O Q902 DTC114YSA-T D.TRANSISTOR DTC114YS
294 O Q903 DTC114YSA-T D.TRANSISTOR DTC114YS
295 ! O Q904 2KTB1366Y8 TRANSISTOR KTB1366
296 O Q905 2KTC3199GP0008 TRANSISTOR KTC3199
297 O Q906 2KTC3199GP0008 TRANSISTOR KTC3199
298 ! O Q907 2KTB1366Y8 TRANSISTOR KTB1366
299 O Q908 2KTA1267GP0008 TRANSISTOR KTA1267GR
300 O Q909 KRA107M-T D.TRANSISTOR A107M
301 O Q910 DTC114YSA-T D.TRANSISTOR DTC114YS
302 O Q911 2KTC3199GP0008 TRANSISTOR KTC3199
303 O Q912 DTC114YSA-T D.TRANSISTOR DTC114YS
304 O R101 NRSA63J-393X MG RESISTOR 39K
305 O R102 NRSA63J-682X MG RESISTOR 6.8K
306 O R103 NRSA63J-222X MG RESISTOR 2.2K
307 O R104 NRSA63J-222X MG RESISTOR 2.2K
308 O R105 NRSA63J-154X MG RESISTOR 150K
309 O R106 NRSA63J-682X MG RESISTOR 5.6K
310 O R107 NRSA63J-0R0X MG RESISTOR 00
311 O R108 NRSA63J-103X MG RESISTOR 10K
312 O R109 NRSA63J-122X MG RESISTOR 1.2K
313 O R110 NRSA63J-222X MG RESISTOR 2.2K
314 O R111 NRSA63J-222X MG RESISTOR 2.2K
315 O R112 NRSA63J-562X MG RESISTOR 5.6K
316 O R113 NRSA63J-103X MG RESISTOR 10K
317 O R114 NRSA63J-102X MG RESISTOR 1K
318 O R115 NRSA63J-223X MG RESISTOR 22K
319 O R117 NRSA63J-222X MG RESISTOR 2.2K
320 O R118 NRSA63J-472X MG RESISTOR 4.7K
321 O R119 NRSA63J-103X MG RESISTOR 10K
322 O R120 NRSA63J-563X MG RESISTOR 56K
323 O R121 NRSA63J-152X MG RESISTOR 1.5K
324 O R123 NRSA63J-473X MG RESISTOR 47K
325 O R124 NRSA63J-152X MG RESISTOR 1.5K
326 O R125 QRM024K-R22 MP RESISTOR 0.22.2W
327 O R126 QRM024K-R22 MP RESISTOR 0.22.2W
328 ! O R127 RF1510045N0000 FUSI RESISTOR 150-1/4W
329 O R128 NRSA63J-220X MG RESISTOR 22
330 O R129 NRSA63J-220X MG RESISTOR 22
331 O R130 NRSA63J-220X MG RESISTOR 22
332 O R131 NRSA63J-103X MG RESISTOR 10K
333 ! O R132 RF3910045N0000 FUSI RESISTOR 390-1/4W
334 ! O R133 RF3910045N0000 FUSI RESISTOR 390-1/4W
335 O R134 NRSA63J-103X MG RESISTOR 10K
336 O R136 NRSA63J-102X MG RESISTOR 1K
337 O R137 NRSA63J-104X MG RESISTOR 100K
338 O R138 NRSA63J-102X MG RESISTOR 1K
339 O R139 QRE141J-103 C RESISTOR 10K
340 O R150 NRSA63J-220X MG RESISTOR 22
341 O R151 NRSA63J-153X MG RESISTOR 15K
342 O R152 NRSA63J-473X MG RESISTOR 47K
3-37
