 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
229 O JR13 NRSA63J-0R0X MG RESISTOR 00
230 O L101 2600702 Chock Coil 1uH
231 O L1053 18A843556N0002 F-BEAD F-B 843556
232 O L1051 26047000KM0024 INDUCTOR 4.7uH
233 O L1052 26047000KM0024 INDUCTOR 4.7uH
234 O L201 2600702 Chock Coil 1uH
235 O L301 605071 BIAS-COIL 864306
236 O L302 NIL JUMPER WIRE JW
237 O L304 18A843556N0002 F-BEAD F-B 843556
238 O L305 26100000KM0024 INDUCTOR 10uH
239 O L401 NIL JUMPER WIRE JW
240 O L501 NIL JUMPER WIRE JW
241 O Q101 2KTC3199GP0008 TRANSISTOR KTC3199
242 O Q103 2KTC3199GP0008 TRANSISTOR KTC3199
243 O Q104 2KTA1267GP0008 TRANSISTOR KTA1267GR
244 O Q105 2KTC3199GP0008 TRANSISTOR KTC3199
245 O Q201 2KTC3199GP0008 TRANSISTOR KTC3199
246 O Q203 2KTC3199GP0008 TRANSISTOR KTC3199
247 O Q204 2KTA1267GP0008 TRANSISTOR KTA1267GR
248 O Q205 2KTC3199GP0008 TRANSISTOR KTC3199
249 O Q301 KRA107M-T D.TRANSISTOR A107M
250 O Q302 KTC3200GR TRANSISTOR KTC3200
251 O Q303 2KTC3203YP0008 TRANSISTOR KTC3203Y
252 O Q304 2KTA1267GP0008 TRANSISTOR KTA1267GR
253 O Q305 DTC144ESTP D.TRANSISTOR DTC144ES
254 O Q307 2KTC3199GP0008 TRANSISTOR KTC3199
255 O Q308 DTC144ESTP D.TRANSISTOR DTC144ES
256 O Q309 KTA1273/Y/-T TRANSISTOR KTA1273Y
257 O Q310 2KTC3199GP0008 TRANSISTOR KTC3199
258 O Q311 KTA1273/Y/-T TRANSISTOR KTA1273Y
259 O Q312 2KTC3199GP0008 TRANSISTOR KTC3199
260 O Q313 KTA1273/Y/-T TRANSISTOR KTA1273Y
261 O Q314 DTC114YSA-T D.TRANSISTOR DTC114YS
262 O Q315 2KTC3199GP0008 TRANSISTOR KTC3199
263 O Q316 2KTC3199GP0008 TRANSISTOR KTC3199
264 O Q317 2KTC3199GP0008 TRANSISTOR KTC3199
265 O Q318 DTC114YSA-T D.TRANSISTOR DTC114YS
266 O Q319 2KTA1270YP0008 TRANSISTOR KTA1267Y
267 O Q321 DTC114YSA-T D.TRANSISTOR DTC114YS
268 O Q322 KRA107M-T D.TRANSISTOR A107M
269 O Q323 KRA107M-T D.TRANSISTOR A107M
270 O Q324 KRA107M-T D.TRANSISTOR A107M
271 O Q325 DTC114YSA-T D.TRANSISTOR DTC114YS
272 O Q327 2KTA1267GP0008 TRANSISTOR KTA1267GR
273 O Q331 KTC3200GR TRANSISTOR KTC3200
274 O Q332 2KTA1268GP0008 TRANSISTOR KTA1268
275 O Q333 DTC114YSA-T D.TRANSISTOR DTC114YS
276 O Q334 KRA107M-T D.TRANSISTOR KRA107M
277 O Q335 KRA107M-T D.TRANSISTOR A107M
278 O Q336 2KTC3199GP0008 TRANSISTOR KTC3199
279 O Q337 2KTC3199GP0008 TRANSISTOR KTC3199
280 O Q338 2KTC3199GP0008 TRANSISTOR KTC3199
281 O Q339 DTC114YSA-T D.TRANSISTOR DTC114YS
282 O Q401 2SD2144S/VW/-T TRANSISTOR 2SD2144S
283 O Q402 2SD2144S/VW/-T TRANSISTOR 2SD2144
284 O Q403 2KTC3199GP0008 TRANSISTOR KTC3199
285 O Q404 2KTC3199GP0008 TRANSISTOR KTC3199
3-36
