 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
172 O D308 11ES2-T4 SI DIODE 1SS133
173 O D309 11ES2-T4 SI DIODE 1SS133
174 O D310 11ES2-T4 SI DIODE 1SS133
175 O D311 11ES2-T4 SI DIODE 1SS133
176 O D312 11ES2-T4 SI DIODE 1SS133
177 O D313 11ES2-T4 SI DIODE 1SS133
178 O D314 11ES2-T4 SI DIODE 1SS133
179 O D321 11ES2-T4 SI DIODE 1SS133
180 O D322 11ES2-T4 SI DIODE 1SS133
181 O D323 31N40011 SI DIODE 1N4001
182 O D324 11ES2-T4 SI DIODE 1SS133
183 O D325 11ES2-T4 SI DIODE 1SS133
184 O D326 11ES2-T4 SI DIODE 1SS133
185 O D327 11ES2-T4 SI DIODE 1SS133
186 O D328 11ES2-T4 SI DIODE 1SS133
187 O D329 NIL NM
188 O D330 NIL NM
189 O D331 11ES2-T4 SI DIODE 1SS133
190 O D332 11ES2-T4 SI DIODE 1SS133
191 O D333 31SS133N0007 SI DIODE 1SS133
192 ! O D901 3RS603M1 BRIDGE DIODE RS603M
193 ! O D902 31N40011 SI DIODE 1N4001
194 ! O D903 31N40011 SI DIODE 1N4001
195 ! O D904 31N40011 SI DIODE 1N4001
196 ! O D905 31N40011 SI DIODE 1N4001
197 O D906 31N40011 SI DIODE 1N4001
198 O D907 MTZJ33C-T77 Z DIODE MTZJ33C
199 O D908 MTZ6.2JB Z DIODE MTZJ6.2B
200 O D909 11ES2-T4 SI DIODE 1S133
201 O D910 MTZ6.2JB Z DIODE MTZJ6.2B
202 O D911 3MTZJ5.6AM0007 Z DIODE MTZJ5.6A
203 O D912 MTZJ12C Z DIODE MTZJ12C
204 O D913 3MTZJ11BM0007 Z DIODE MTZJ11B
205 O D915 MTZJ6.8B Z DIODE MTZJ6.8B
206 O D916 11ES2-T4 SI DIODE 1SS133
207 O W1051 12P402341 CONN. ASSY 4P-2.5mm
208 O J1053 23B0112 MINI JACK MSJ-2000
209 O IC102 113241 IC BA1521B
210 O IC103 113231 IC TDA7440D
211 ! O IC304 113191 IC STK402-090
212 O IC401 TA8189N IC TA8189
213 O IC402 113221 IC 74HC4094
214 O J303 23F0251 SP 4P TERMINAL MSP-103V-04
215 O JA301 23B0931 RCA W/R JACK MSP-242V3
216 O JD75 NIL JUMPER WIRE JW
217 O JR1 NRSA63J-0R0X MG RESISTOR 00
218 O JR2 NRSA63J-0R0X MG RESISTOR 00
219 O JR3 NRSA63J-0R0X MG RESISTOR 00
220 O JR4 NRSA63J-0R0X MG RESISTOR 00
221 O JR5 NRSA63J-0R0X MG RESISTOR 00
222 O JR6 NRS181J-0R0X MG RESISTOR 00
223 O JR7 NRSA63J-0R0X MG RESISTOR 00
224 O JR8 NRSA63J-0R0X MG RESISTOR 00
225 O JR9 NRSA63J-0R0X MG RESISTOR 00
226 O JR10 NRSA63J-0R0X MG RESISTOR 00
227 O JR11 NRSA63J-0R0X MG RESISTOR 00
228 O JR12 NRSA63J-0R0X MG RESISTOR 00
3-35
