 Electrical parts list (K30 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
115 O C414 NCB31HK-102X C CAPACITOR 1000P
116 O C415 QETM1HM-475 E CAPACITOR 4.7U/50V
117 O C417 NDC31HJ-471X C CAPACITOR 470P
118 O C418 NCB31HK-222X C CAPACITOR 2200P
119 O C501 NCB31HK-681X C CAPACITOR 680P
120 O C502 NCB31HK-681X C CAPACITOR 680P
121 O C503 NDC31HJ-330X C CAPACITOR 33P
122 O C504 QFV42AJ-183 MF CAPACITOR 0.018-M
123 O C505 QETM1AM-107 E CAPACITOR 100/10V
124 O C507 QETM1HM-475 E CAPACITOR 4.7/50V
125 O C508 QETM1HM-475 E CAPACITOR 4.7/50V
126 O C509 NCB31HK-102X C CAPACITOR 1000P
127 O C510 NCB31HK-332X C CAPACITOR 3300P
128 O C511 QETM1EM-106 E CAPACITOR 10U/25V
129 O C512 NIL NM
130 O C513 CH181500JM0130 C CAPACITOR 180P
131 O C514 NCB31HK-102X C CAPACITOR 1000P
132 O C515 QETM1HM-475 E CAPACITOR 4.7U/50V
133 O C517 NDC31HJ-471X C CAPACITOR 470P
134 O C518 NCB31HK-222X C CAPACITOR 2200P
135 O C901 QFLA2AJ-682 M CAPACITOR 0.068-M
136 O C902 QFLA2AJ-682 M CAPACITOR 0.068-M
137 O C903 QFLA2AJ-682 M CAPACITOR 0.068-M
138 O C904 QFLA2AJ-682 M CAPACITOR 0.068-M
139 ! O C905 CE33863MSN3 E CAPACITOR 3300/63V
140 ! O C906 CE33863MSN3 E CAPACITOR 3300/63V
141 O C907 NCB21HJ-104X C CAPACITOR 0.1
142 O C908 NCB21HJ-104X C CAPACITOR 0.1
143 O C909 NCB21HJ-104X C CAPACITOR 0.1
144 O C910 NCB21HJ-104X C CAPACITOR 0.1
145 ! O C911 CE47825M0 E CAPACITOR 4700/25V
146 O C912 QETL1JM-476 E CAPACITOR 47/63V
147 O C913 QETM1HM-226 E CAPACITOR 22/50V
148 O C914 NCB31HK-103X C CAPACITOR 0.01
149 O C915 QETM1HM-226 E CAPACITOR 22/50V
150 O C916 QETM1EM-106 E CAPACITOR 10/25V
151 O C917 QETM1HM-225 E CAPACITOR 2.2/50V
152 O C918 NCB31HK-103X C CAPACITOR 0.01
153 O C919 QETM1AM-107 E CAPACITOR 100/10V
154 O C920 NCB21HJ-104X C CAPACITOR 0.1
155 O C921 QETM1CM-107 E CAPACITOR 100/16V
156 O C922 QETM1EM-106 E CAPACITOR 10/25V
157 O C1051 NCB31HK-102X C CAPACITOR 1000P
158 O C1052 NCB31HK-102X C CAPACITOR 1000P
159 O CN101 12S40047 CONNECTOR 4P 2.5mm
160 O CN202 12S110020 FFC CONNECTOR 11P 1.25mm
161 O CN203 12S800421 FFC CONNECTOR 8P 1.25mm
162 O CN305 12S130027 FFC CONNECTOR 13P 1.25mm
163 O CN307 12S30039 CONNECTOR 3P 2.0mm
164 O CN308 12S80024 CONNECTOR 8P 2.0mm
165 O CN701 12S110020 FFC CONNECTOR 11P 1.25mm
166 O CN702 12S210004 FFC CONNECTOR 21P 1.25mm
167 O CN951 12P90047 FLAT CABLE ASSY 9P 2.5mm
168 O CN982 NIL NO MOUNT NM
169 O D304 11ES2-T4 SI DIODE 1SS133
170 O D305 11ES2-T4 SI DIODE 1SS133
171 O D307 UZ5.1BSB Z DIODE MTZJ5.1B
