JVC MX-K10

Parts list (Exploded view of general assembly)
Block No. M1MM
! ltem Parts number Parts name Q'ty Description Area
1 BI109808010101 WINDOW CASS L 1
2 BI109809010101 WINDOW CASS R 1
3 BI109806010101 BOX CASS L 1
1
4 BI109807010201 BOX CASS R
5 BI109819010201 KNOB VOLUME 1
6 BI109823010101 KEY BASS 1
7 BI109805010201 PANEL CD 1
8 BI109810040101 WINDOW DISPLAY 1
9 BI109827010101 KEY POWER A 1
10 BI109835010101 LOGO JVC 1
11 BI109834010101 RING VOLUME 1
1
12 BI109969010201 SPACER
13 BI301781010101 MIRROR SHEET 1
1
14 BI109804910201 PANEL FRON
T
15 BI301388010101 DAMP 2
2
2
2
16 BI109840010101 LOCKER
17 BI202408010101 SPRING LOCKER
18 BI109841010101 HOLDER LOCKER
19 BI202266010101 SPRING CASS R 1
20 BI301789010101 BUSHING 1
21 BI202262010401 BOTTOM PLATE 1
4
22 BI103362020102 RUBBER FOO
T
23 BI202103010101 HOLDER SENSER
24 BI109815010101 CAP, CD CHANGE 1
1
BI109816010101 CAP, CD CHANGE 1
BI109817010101 CAP, CD CHANGE 1
25 BI109822010101 KEY CD CHANG 1
1
1
26 BI3101441 CASSETTE DEC
K
CMAT6Z219A
27 BI109832010101 KEY CLOC
K
28 BI109828010101 KEY DEMO 1
29 BI109829010101 KEY PLAY/STOP 1
30 PWB PHONE ASSY 1 251100G01V(B) K30J/C
PWB PHONE ASSY 1 251131G01V(B) K10J/C
31 BI109825010201 KEY OPEN/CLOSE 1
32 BI202268010101 BRACKET-PWB-A 1
33 BI109831010201 KEY DUBBING 1
34 BI109826010201 KEY REPEAT 1
35 PWB KEY3 ASSY 1
1
1
1
1
1
251099G01V(D)
36 BI109811010101 CAP FUNCTION SE
T
BI109812010101 CAP FUNCTION SE
T
BI109813010101 CAP FUNCTION SE
T
BI109814010101 CAP FUNCTION SE
T
37 BI109821010101 KEY FUNCTION
1
38 PWB CD ASSY 1 251098G01V
39 BI681MXK30000 CD CHANGER UNI
T
CD99CJ
40 BI109836910201 PANEL TOP 1
41 BI202303010201 BRACKET-PWB-B 1
3-6
