JVC MX-K10

Parts list (Exploded view of general assembly)
Block No. M1MM
! ltem Parts number Parts name Q'ty Description Area
42 BI2110405020010 PW TRANSFORMER 1 K30J/C
BI2110405040010 PW TRANSFORMER 1 K10J/C
43 PWB PT ASSY 1 251100G01V(C) K30J/C
PWB PT ASSY 1 251131G01V(C) K10J/C
44 BI109837910401 PANEL SIDE L 1
45 PWB MAIN ASSY 1 251100G01V(A) K30J/C
PWB MAIN ASSY 1 251131G01V(A) K10J/C
46 BI109838910401 PANEL SIDE R 1
47 PWB KEY1 ASSY 1 251099G01V(B)
48 BI109824010201 KEY SOUNCL MODE 1
49 PWB KEY2 ASSY 1 251099G01V(C)
50 BI301773010101 DOUBLE SIDE EVA
51 BI202267010101 HOLDER-VFD 2
2
2
52 PWB DISPLAY ASSY 1 251099G01V(A)
53 BI202264010101 BRACKET-ADAPTO
R
54 PWB 2B TUNER ASSY 1 251111G01V
55 BI202321010101 HEAT SINK K30J 1 K30J/C
BI202316010201 HEAT SINK K10 1
1
K10J
/
C
56 BI202304010101 HOLDER TUNE
R
57 BI202319020101 PANEL REAL 1 K30J/C
BI202315020101 PANEL REAL 1
1
K10J/C
58 BI109970910101 HEAT SINK COVER K30J/C
59 BI109818010101 LES LED 1
60 BIRM000604S3 SCREW 21 RH/MS 3x8mm K30J/C
BIRM000604S3 SCREW 16 RH/MS 3x8mm K10J/C
61 BIRM000601S3 SCREW 3 RH/MS 3x6mm K30J/C
BIRM000601S3 SCREW 3 RH/MS 3x6mm K10J/C
62 BIKT000627 SCREW 2 KH/TS 3x12mm
63 BIBT000418 SCREW 31 BT/TS 2.6x8mm
64 BIPMW001101S3 SCREW 4 PMW/TS 4x8mm
65 BI202265010101 SPRING CASS L 1
66 BIRT000618B2 SCREW 1
1
1
RH/TS 3x6mm K30J/C
BIRT000618B2 SCREW 6 RH/TS 3x6mm K10J/C
67 BIBT000206 SCREW 2 BH/TS 2x8mm
68 BIBT0006091 SCREW 2 BH/TS 3x14mm K30J/C
69 BIRT000611B3 SCREW 7 RH/TS 3x8mm K30J/C
BIRT000611B3 SCREW 5 RH/TS 3x8mm K10J/C
70 BIBM000618 SCREW 2 BT/MS 3x6mm
71 PWB PHONE HOLDER 1 251099G01V
72 BI202337010101 BRACKET FORN
T
73 BI202348010101 BRACKET CD DEC
K
74 BI202337010101 BRACKET MB 1
75 BIRT000617B3 SCREW 2 RH/TS 3x10mm
! 76 403011 FUSE 1 3.15A 250V K30J F951
! 77 402991 FUSE 2 1.6A 250V K10J F951 F952
402991 FUSE 1 1.6A 250V K30J F952
! 78 1400862 A CORDC 1 UL/CSA
3-7
