JVC MX-K10

 Electrical parts list (CD changer mechanism)
!
Item
Location
Parts number Parts name Q'ty. Description Area
1 BI3199801000 GEAR PLATE 1
2 BI3199802000 GUIDE PLATE 2
3 BI3199804000 UP COVER PLATE 1
4 BI3499801000 SHAFT PULLEY 1
5 BI3499802000 SHAFT SWING 1
6 BI3599801001 T/T SWITCH SPRING 1
7 BI3599802000 SWING SPRING 1
8 BI3599803000 SPRING BIG 1
9 BI3599804000 SPRING SMALL 1
10 BI3599805000 TOWER FORM SPRING 1
11 BI3599806000 CUSHION HARD 1
12 BI3599807000 CUSHION SOFT 3
13 BI36CJ000000 M-399 OPTIMA-7 1 CD MECH.W/PICK UP
15 BI3799802000 CUSHION RUBBER 4
16 BI4299801001 BASE 1
17 BI4299802000 TRAY 1
18 BI4299803002 TURN CHANGER 1
19 BI4299804000 INERTIA GEAR (A) 1
20 BI4299821000 HOLDER DISC 1
21 BI4299806000 T/T GEAR 2
22 BI4297307000 OBLIQUE GEAR 1
23 BI4299808000 SCREW STICK 1
24 BI4299809000 T/T LEVER LOCK 1
25 BI4299810000 PULLEY 1
26 BI4299811000 PULLEY GEAR 1
27 BI4299812000 BASE CHANGE 1
1
28 BI4299813000 TRANSMISSION
29 BI4299814001 MECHA GEAR 1
30 BI4299815000 MECHA HOLDER 1
31 BI4299816001 INERTIA GEAR (B) 4
32 BI4299817000 ROLLER 2
33 BI4299818000 BASE CD MECHANISM 1
34 BI4299819000 BUFFER BASE 1
35 BI4399801000 BELT 1
36 BI4799801000 BASE CHANGE FELT 1
37 BI4799803001 PVC PLATE 1
38 BI4799804000 MAGNET DISC CRAMP 1
39 BI5099807000 WIRE ASSY 6P 1
40 BI5099808000 WIRE ASSY 3P 1
41 BI5099809000 WIRE ASSY 6P 1
42 BI5099811001 WIRE ASSY 6P 1
43 BI5099812001 FLEX CABLE 15P 1
44 BI6599801000 SWITCH 3
45 BI6599802000 SWITCH 1
46 BI6994301000 MOTOR 1
47 BI6999801000 MOTOR 1
48 BI86000102J3 SCREW 2 M2.6 x 5.0
49 BI86000115F1 SCREW 1 M2.0 x 12.0
50 BI86000125E1 SCREW 3 M1.7 x 8.0
51 BI86000135E1 SCREW 1 M3.0 x 8.0
52 BI86000145E2 SCREW 4 M1.7 x 8.0
53 BI865F31B075 SCREW 4 M2.0 x 7.5
54 BI865F31B120 SCREW 2 M2.0 x 12.0
55 BI865J31B080 SCREW 5 M2.6 x 8.0
56 BI8811231206 WASHER 4 2.2 x 13.0 x 0.6
57 BI4500001100 YST BAR CODE 1
58 BI6599801001 SWITCH 1
3-9
