 MX-K30/MX-K10 FRONT DISPLAY UICOM SELECTION
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
O R713 NRSA63J-473X MG RESISTOR 47K
O R714 NRSA63J-222X MG RESISTOR 2.2K
O R715 NRSA63J-473X MG RESISTOR 47K
O R716 NRSA63J-222X MG RESISTOR 2.2K
O R717 NRSA63J-102X MG RESISTOR 1K
O R718 NRSA63J-473X MG RESISTOR 47K
O R719 NRSA63J-222X MG RESISTOR 2.2K
O R720 NRSA63J-102X MG RESISTOR 1K
O R721 NRSA63J-102X MG RESISTOR 1K
O R722 NRSA63J-102X MG RESISTOR 1K
O R723 NRSA63J-221X MG RESISTOR 220
O R724 NRSA63J-102X MG RESISTOR 1K
O R725 NRSA63J-331X MG RESISTOR 330
O R726 NRSA63J-103X MG RESISTOR 10K
O R727 NRSA63J-102X MG RESISTOR 1K
O R728 NRSA63J-102X MG RESISTOR 1K
O R729 NRSA63J-102X MG RESISTOR 1K
O R730 NRSA63J-102X MG RESISTOR 1K
O R731 NRSA63J-102X MG RESISTOR 1K
O R732 NRSA63J-102X MG RESISTOR 1K
O R733 NRSA63J-472X MG RESISTOR 4.7K
O R734 NRSA63J-472X MG RESISTOR 4.7K
O R736 NRSA63J-101X MG RESISTOR 100
O R737 NRSA63J-101X MG RESISTOR 100
O R738 NRSA63J-221X MG RESISTOR 220
O R739 NRSA63J-221X MG RESISTOR 220
O R740 NRSA63J-221X MG RESISTOR 220
O R741 NRSA63J-331X MG RESISTOR 330
O R742 NRSA63J-222X MG RESISTOR 2.2K
O R743 NRSA63J-222X MG RESISTOR 2.2K
O R744 NRSA63J-221X MG RESISTOR 220
O R745 NRSA63J-222X MG RESISTOR 2.2K
O R746 NRSA63J-222X MG RESISTOR 2.2K
O R747 NRSA63J-222X MG RESISTOR 2.2K
O R748 NRSA63J-222X MG RESISTOR 2.2K
O R749 NRSA63J-472X MG RESISTOR 4.7K
O R750 NRSA63J-472X MG RESISTOR 4.7K
O R751 NRSA63J-472X MG RESISTOR 4.7K
O R752 NRSA63J-472X MG RESISTOR 4.7K
O R753 NRSA63J-222X MG RESISTOR 2.2K
O R754 NRSA63J-222X MG RESISTOR 2.2K
O R755 NRSA63J-222X MG RESISTOR 2.2K
O R756 NRSA63J-222X MG RESISTOR 2.2K
O R757 NRSA63J-102X MG RESISTOR 1K
O R758 NRSA63J-222X MG RESISTOR 2.2K
O R759 NRSA63J-2R2X MG RESISTOR 2.2
O R760 NRSA63J-2R2X MG RESISTOR 2.2
O R761 NRSA63J-473X MG RESISTOR 47K
O R768 NRSA63J-104X MG RESISTOR 100K
O R769 NRSA63J-102X MG RESISTOR 1K
O R770 NRSA63J-222X MG RESISTOR 2.2K
O R771 NRSA63J-221X MG RESISTOR 220
O R772 NRSA63J-222X MG RESISTOR 2.2K
O R773 NRSA63J-222X MG RESISTOR 2.2K
O R774 NRSA63J-182X MG RESISTOR 1.8K
O R775 NRSA63J-102X MG RESISTOR 1K
O R776 NRSA63J-103X MG RESISTOR 10K
O R777 NRSA63J-473X MG RESISTOR 47K
O R778 NRSA63J-102X MG RESISTOR 1K
O R779 NRSA63J-103X MG RESISTOR 10K
O R780 NRSA63J-222X MG RESISTOR 2.2K
O R781 NRSA63J-102X MG RESISTOR 1K
O R782 NRSA63J-222X MG RESISTOR 2.2K
O R783 NRSA63J-473X MG RESISTOR 47K
O R784 NRSA63J-222X MG RESISTOR 2.2K
O R785 NRSA63J-222X MG RESISTOR 2.2K
O R786 NRSA63J-103X MG RESISTOR 10K
O R787 NRSA63J-103X MG RESISTOR 10K
O R788 NRSA63J-102X MG RESISTOR 1K
O R789 NRSA63J-222X MG RESISTOR 2.2K
