 MX-K30/MX-K10 FRONT DISPLAY UICOM SELECTION
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
O C701 NCB31EK-104X C CAPACITOR 0.1
O C702 QETM0JM-227 E CAPACITOR 220/6.3V
O C703 QETM0JM-227 E CAPACITOR 220/6.3V
O C704 QETM0JM-227 E CAPACITOR 220/6.3V
O C705 NCB31HK-102X C CAPACITOR 0.001
O C706 NCB31HK-102X C CAPACITOR 0.001
O C707 NDC31HJ-390X C CAPACITOR 39P
O C708 NDC31HJ-330X C CAPACITOR 33P
O C709 NDC31HJ-220X C CAPACITOR 22P
O C710 NDC31HJ-220X C CAPACITOR 22P
O C711 NDC31HJ-220X C CAPACITOR 22P
O C712 NDC31HJ-220X C CAPACITOR 22P
O C713 NCB31EK-104X C CAPACITOR 0.1
O C714 NCB31HK-103X C CAPACITOR 0.01
O C715 NCB31HK-102X C CAPACITOR 0.001
O C716 QETM1AM-476 E CAPACITOR 47/10V
O C717 NCB31EK-104X C CAPACITOR 0.1
O C718 QETM1HM-226 E CAPACITOR 22uF/50V
O C719 QETM1HM-226 E CAPACITOR 22uF/50V
O C720 NDC31HJ-151X C CAPACITOR 150P
O C721 NDC31HJ-151X C CAPACITOR 150P
O C723 QETM1HM-105 E CAPACITOR 1uF/50V
O C740 NDC31HJ-101X C CAPACITOR 100P
O C1001 NCB31HK-103X C CAPACITOR 0.01
O C1002 NCB31HK-103X C CAPACITOR 0.01
O CN701 12S110021 FFC CONNECTOR 11P H 1.25mm
O CN702 12S210005 FFC CONNECTOR 21P H 1.25mm
O CN703 12S220005 FFC CONNECTOR 22P H 1.25mm
O D701 11ES2-T4 SI DIODE 1SS133
O D702 11ES2-T4 SI DIODE 1SS133
O D703 11ES2-T4 SI DIODE 1SS133
O D705 11ES2-T4 SI DIODE 1SS133
O FL701 2701601 FL DISPLAY BJ828GNK
O FW701A&B 1204091 CONN. WIRE 10PIN FLAT CABLE
O FW702A&B 1203941 CONN. WIRE 3PIN FLAT CABLE
O FW703A&B 1203931 CONN. WIRE 3PIN FLAT CABLE
O IC701 113171 IC MN101C35D
O IC702 RPM6938-SV4 IR.UNIT IC RPM6938-V4
O JK1 NIL MIC JACK NO MOUNT
O JR701 NRSA63J-0R0X MG RESISTOR 0
O JR702 NRSA63J-0R0X MG RESISTOR 0
O JR749 NRSA63J-0R0X MG RESISTOR 0
O L701 26220000KN0024 FIXED INDUCTOR 22uH
O L702 26100000KM0024 FIXED INDUCTOR 10uH
O L703 18A843556N0002 F-BEAD F.B 843556
O L707 26100000KM0024 FIXED INDUCTOR 10uH
O LED100 28B4531EP0110 RED LED BL-B4531E
O Q701 2KTC3199GP0008 TRANSISTOR KTC3199GR
O Q702 2KTC3199GP0008 TRANSISTOR KTC3199GR
O Q703 2KTC3199GP0008 TRANSISTOR KTC3199GR
O Q704 2KTC3195YP0008 TRANSISTOR KTC3195Y
O Q705 2KTC3195YP0008 TRANSISTOR KTC3195Y
O Q707 DTC114YSA-T D.TRANSISTOR DTC114YS
O Q711 KRA102M-T D.TRANSISTOR KRA102M
O Q712 KRA102M-T D.TRANSISTOR KRA102M
O Q713 DTC114YSA-T D.TRANSISTOR DTC114YS
O Q714 2KTC3199GP0008 TRANSISTOR KTC3199GR
O Q715 2KTC3199GP0008 TRANSISTOR KTC3199GR
O R701 NRSA63J-473X MG RESISTOR 47K
O R702 NRSA63J-473X MG RESISTOR 47K
O R703 NRSA63J-473X MG RESISTOR 47K
O R704 NRSA63J-103X MG RESISTOR 10K
O R705 NRSA63J-103X MG RESISTOR 10K
O R706 NRSA63J-103X MG RESISTOR 10K
O R707 NRSA63J-102X MG RESISTOR 1K
O R708 NRSA63J-103X MG RESISTOR 10K
O R709 NRSA63J-102X MG RESISTOR 1K
O R710 NRSA63J-102X MG RESISTOR 1K
O R711 NRSA63J-102X MG RESISTOR 1K
O R712 NRSA63J-102X MG RESISTOR 1K
3-11
