JVC MX-K10

 Electrical parts list (MX-K10/K30 Tuner selection)
!
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
O R758 NRSA63J-222X MG RESISTOR 2.2K
O R759 NRSA63J-2R2X MG RESISTOR 2.2
O R760 NRSA63J-2R2X MG RESISTOR 2.2
O R761 NRSA63J-473X MG RESISTOR 47K
O R768 NRSA63J-104X MG RESISTOR 100K
O R769 NRSA63J-102X MG RESISTOR 1K
O R770 NRSA63J-222X MG RESISTOR 2.2K
O R771 NRSA63J-221X MG RESISTOR 220
O R772 NRSA63J-222X MG RESISTOR 2.2K
O R773 NRSA63J-222X MG RESISTOR 2.2K
O R774 NRSA63J-182X MG RESISTOR 1.8K
O R775 NRSA63J-102X MG RESISTOR 1K
O R776 NRSA63J-103X MG RESISTOR 10K
O R777 NRSA63J-473X MG RESISTOR 47K
O R778 NRSA63J-102X MG RESISTOR 1K
O R779 NRSA63J-103X MG RESISTOR 10K
O R780 NRSA63J-222X MG RESISTOR 2.2K
O R781 NRSA63J-102X MG RESISTOR 1K
O R782 NRSA63J-222X MG RESISTOR 2.2K
O R783 NRSA63J-473X MG RESISTOR 47K
O R784 NRSA63J-222X MG RESISTOR 2.2K
O R785 NRSA63J-222X MG RESISTOR 2.2K
O R786 NRSA63J-103X MG RESISTOR 10K
O R787 NRSA63J-103X MG RESISTOR 10K
O R788 NRSA63J-102X MG RESISTOR 1K
O R789 NRSA63J-222X MG RESISTOR 2.2K
O R790 NRSA63J-102X MG RESISTOR 1K
O R791 NRSA63J-101X MG RESISTOR 100
O R792 NRSA63J-331X MG RESISTOR 330
O R1001 NRSA63J-681X MG RESISTOR 680
O R1002 NRSA63J-681X MG RESISTOR 680
O R1003 NRSA63J-821X MG RESISTOR 820
O R1004 NRSA63J-102X MG RESISTOR 1K
O R1005 NRSA63J-152X MG RESISTOR 1.5K
O R1008 NRSA63J-681X MG RESISTOR 680
O R1009 NRSA63J-681X MG RESISTOR 680
O R1010 NRSA63J-681X MG RESISTOR 680
O R1011 NRSA63J-821X MG RESISTOR 820
O R1012 NRSA63J-102X MG RESISTOR 1K
O R1013 NRSA63J-152X MG RESISTOR 1.5K
O R1014 NRSA63J-222X MG RESISTOR 2.2K
O R1015 NRSA63J-272X MG RESISTOR 2.7K
O R1017 NRSA63J-681X MG RESISTOR 680
O R1018 NRSA63J-681X MG RESISTOR 680
O R1019 NRSA63J-821X MG RESISTOR 820
O R1020 NRSA63J-102X MG RESISTOR 1K
O R1021 NRSA63J-152X MG RESISTOR 1.5K
O R1022 NRSA63J-222X MG RESISTOR 2.2K
O R1023 NRSA63J-272X MG RESISTOR 2.7K
O R1024 NRSA63J-562X MG RESISTOR 5.6K
O R1025 NRSA63J-123X MG RESISTOR 12K
O R1026 NRSA63J-681X MG RESISTOR 680
O R1027 NRSA63J-681X MG RESISTOR 680
O R1028 NRSA63J-821X MG RESISTOR 820
O R1029 NRSA63J-102X MG RESISTOR 1K
O R1030 NRSA63J-152X MG RESISTOR 1.5K
O R1037 NRSA63J-223X MG RESISTOR 22K
3-17
