JVC MX-K10

 Electrical parts list (MX-K10/K30 Tuner selection)
!
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
O R1038 NRSA63J-223X MG RESISTOR 22K
O R1039 NRSA63J-124X MG RESISTOR 120K
O R1040 NRSA63J-124X MG RESISTOR 120K
O R1041 NRSA63J-563X MG RESISTOR 56K
O R1042 NRSA63J-563X MG RESISTOR 56K
O R1043 NRSA63J-473X MG RESISTOR 47K
O R1047 NRSA63J-473X MG RESISTOR 47K
O R1048 NRSA63J-103X MG RESISTOR 10K
O R1060 NRSA63J-473X MG RESISTOR 47K
O R1061 NRSA63J-102X MG RESISTOR 1K
O R1062 NRSA63J-221X MG RESISTOR 220
O R1063 NRSA63J-221X MG RESISTOR 220
O R1064 NRSA63J-123X MG RESISTOR 12K
O R1065 NRSA63J-102X MG RESISTOR 1K
O R1066 NRSA63J-103X MG RESISTOR 10K
O R1067 NRSA63J-102X MG RESISTOR 1K
O R1068 NRSA63J-103X MG RESISTOR 10K
O R1069 NRSA63J-473X MG RESISTOR 47K
O R1070 NRSA63J-473X MG RESISTOR 47K
O R1071 NRSA63J-473X MG RESISTOR 47K
O R1072 NRSA63J-473X MG RESISTOR 47K
O R1073 NRSA63J-473X MG RESISTOR 47K
O R1074 NRSA63J-473X MG RESISTOR 47K
O R1075 NRSA63J-473X MG RESISTOR 47K
O RA701 NRSA63J-473X MG RESISTOR 47K
O RA702 NRSA63J-473X MG RESISTOR 47K
O RA703 NRSA63J-473X MG RESISTOR 47K
O RA704 NRSA63J-473X MG RESISTOR 47K
O RA705 NRSA63J-473X MG RESISTOR 47K
O RA706 NRSA63J-473X MG RESISTOR 47K
O RA707 NRSA63J-473X MG RESISTOR 47K
O RA708 NRSA63J-473X MG RESISTOR 47K
O RA709 NRSA63J-473X MG RESISTOR 47K
O RA710 NRSA63J-473X MG RESISTOR 47K
O RA711 NRSA63J-473X MG RESISTOR 47K
O RA712 NRSA63J-473X MG RESISTOR 47K
O RA713 NRSA63J-473X MG RESISTOR 47K
O RA714 NRSA63J-473X MG RESISTOR 47K
O RA715 NRSA63J-473X MG RESISTOR 47K
O RA716 NRSA63J-473X MG RESISTOR 47K
O RA717 NRSA63J-473X MG RESISTOR 47K
O RA718 NRSA63J-473X MG RESISTOR 47K
O RA719 NRSA63J-473X MG RESISTOR 47K
O RA720 NRSA63J-473X MG RESISTOR 47K
O RA721 NRSA63J-473X MG RESISTOR 47K
O RA722 NRSA63J-473X MG RESISTOR 47K
O RA723 NRSA63J-473X MG RESISTOR 47K
O RA724 NRSA63J-473X MG RESISTOR 47K
O RA725 NRSA63J-473X MG RESISTOR 47K
O RA726 NRSA63J-473X MG RESISTOR 47K
O RA727 NRSA63J-473X MG RESISTOR 47K
O RA728 NRSA63J-473X MG RESISTOR 47K
O RA729 NRSA63J-473X MG RESISTOR 47K
POWER S1001 8EVQ21405P0154 TACT SWITCH EVQ21405R
TAPE S1002 8EVQ21405P0154 TACT SWITCH EVQ21405R
AUX S1003 8EVQ21405P0154 TACT SWITCH EVQ21405R
BAND S1004 8EVQ21405P0154 TACT SWITCH EVQ21405R
3-18
