JVC MX-K10

 Electrical parts list (MX-K10/K30 Tuner selection)
!
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
CANCEL S1005 8EVQ21405P0154 TACT SWITCH EVQ21405R
SET S1006 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD S1007 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD1 S1008 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD2 S1009 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD3 S1010 8EVQ21405P0154 TACT SWITCH EVQ21405R
EJECT S1011 8EVQ21405P0154 TACT SWITCH EVQ21405R
DISC S1012 8EVQ21405P0154 TACT SWITCH EVQ21405R
DECKA/B S1013 8EVQ21405P0154 TACT SWITCH EVQ21405R
TIM/CLK S1014 8EVQ21405P0154 TACT SWITCH EVQ21405R
STOP S1015 8EVQ21405P0154 TACT SWITCH EVQ21405R
TUN- S1016 8EVQ21405P0154 TACT SWITCH EVQ21405R
TUN+ S1017 8EVQ21405P0154 TACT SWITCH EVQ21405R
PRESET- S1018 8EVQ21405P0154 TACT SWITCH EVQ21405R
PRESET+ S1019 8EVQ21405P0154 TACT SWITCH EVQ21405R
ROCK S1020 8EVQ21405P0154 TACT SWITCH EVQ21405R
CLASSIC S1021 8EVQ21405P0154 TACT SWITCH EVQ21405R
POP S1022 8EVQ21405P0154 TACT SWITCH EVQ21405R
A.BASS S1023 8EVQ21405P0154 TACT SWITCH EVQ21405R
ECO S1024 8EVQ21405P0154 TACT SWITCH EVQ21405R
REC S1025 8EVQ21405P0154 TACT SWITCH EVQ21405R
DUBBIN S1026 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD REC S1027 8EVQ21405P0154 TACT SWITCH EVQ21405R
REPEAT S1028 8EVQ21405P0154 TACT SWITCH EVQ21405R
PROGRAM
S1029 8EVQ21405P0154 TACT SWITCH EVQ21405R
RONDOM
S1030 8EVQ21405P0154 TACT SWITCH EVQ21405R
VOL+/- W1001 804221 JOG SWITCH PVB20FHIN
O X701 29ZTA8.0MP0151 CER. RESONATOR 8.0MHz
O X702 2101012 CRYSTAL 32.768KHz
O --------- 202267010101 HOLDER VFD SPTE THK=0.3mm
O --------- 301773010101 TAPE T=1.0mm EVA
---- --------- 251099G01V THK=1.6mm 94V0 Front Comb. PWB
3-19
