 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
115 O C415 QETM1HM-475 E CAPACITOR 4.7U/50V
116 O C417 NDC31HJ-471X C CAPACITOR 470P
117 O C418 NCB31HK-222X C CAPACITOR 2200P
118 O C501 NCB31HK-681X C CAPACITOR 680P
119 O C502 NCB31HK-681X C CAPACITOR 680P
120 O C503 NDC31HJ-330X C CAPACITOR 33P
121 O C504 QFV42AJ-183 MF CAPACITOR 0.018-M
122 O C505 QETM1AM-107 E CAPACITOR 100/10V
123 O C507 QETM1HM-475 E CAPACITOR 4.7/50V
124 O C508 QETM1HM-475 E CAPACITOR 4.7/50V
125 O C509 NCB31HK-102X C CAPACITOR 1000P
126 O C510 NCB31HK-332X C CAPACITOR 3300P
127 O C511 QETM1EM-106 E CAPACITOR 10U/25V
128 O C512 NIL NM
129 O C513 CH181500JM0130 C CAPACITOR 180P
130 O C514 NCB31HK-102X C CAPACITOR 1000P
131 O C515 QETM1HM-475 E CAPACITOR 4.7U/50V
132 O C517 NDC31HJ-471X C CAPACITOR 470P
133 O C518 NCB31HK-222X C CAPACITOR 2200P
134 O C901 QFLA2AJ-682 M CAPACITOR 0.0068-M
135 O C902 QFLA2AJ-682 M CAPACITOR 0.0068-M
136 O C903 QFLA2AJ-682 M CAPACITOR 0.0068-M
137 O C904 QFLA2AJ-682 M CAPACITOR 0.0068-M
138 ! O C905 CE22850M2 E CAPACITOR 2200/50V
139 ! O C906 CE22850M2 E CAPACITOR 2200/50V
140 O C907 NCB21HJ-104X C CAPACITOR 0.1
141 O C908 NCB21HJ-104X C CAPACITOR 0.1
142 O C909 NCB21HJ-104X C CAPACITOR 0.1
143 O C910 NCB21HJ-104X C CAPACITOR 0.1
144 ! O C911 CE47825M0 E CAPACITOR 4700/25V
145 O C912 QETL1JM-476 E CAPACITOR 47/63V
146 O C913 QETM1HM-226 E CAPACITOR 22/50V
147 O C914 NCB31HK-103X C CAPACITOR 0.01U
148 O C915 QETM1HM-226 E CAPACITOR 22/50V
149 O C916 QETM1EM-106 E CAPACITOR 10/25V
150 O C917 QETM1HM-225 E CAPACITOR 2.2/50V
151 O C918 NCB31HK-103X C CAPACITOR 0.01U
152 O C919 QETM1AM-107 E CAPACITOR 100/10V
153 O C920 NCB21HJ-104X C CAPACITOR 0.1
154 O C921 QETM1CM-107 E CAPACITOR 100/16V
155 O C922 QETM1EM-106 E CAPACITOR 10/25V
156 O C1051 NCB31HK-102X C CAPACITOR 1000P
157 O C1052 NCB31HK-102X C CAPACITOR 1000P
158 O CN101 12S501341 CONNECTOR 5P 2.5mm
159 O CN202 12S110020 FFC CONNECTOR 11P 1.25mm
160 O CN203 12S800421 FFC CONNECTOR 8P 1.25mm
161 O CN305 12S130027 FFC CONNECTOR 13P 1.25mm
162 O CN307 12S30039 CONNECTOR 3P 2.0mm
163 O CN308 12S80024 CONNECTOR 8P 2.0mm
164 O CN701 12S110020 FFC CONNECTOR 11P 1.25mm
165 O CN702 12S210004 FFC CONNECTOR 21P 1.25mm
166 O CN951 12P90047 FLAT CABLE ASSY 9P 2.5mm
167 O CN982 NIL NM
168 O D101 31N40011 SI DIODE 1N4001
169 O D201 NIL JUMPER WIRE JW
170 O D304 11ES2-T4 SI DIODE 1SS133
171 O D305 NIL JUMPER WIRE JW
