JVC MX-K10 - Page 91

 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
172 O D307 UZ5.1BSB Z DIODE MTZJ5.1B
173 O D308 11ES2-T4 SI DIODE 1SS133
174 O D309 11ES2-T4 SI DIODE 1SS133
175 O D310 11ES2-T4 SI DIODE 1SS133
176 O D311 11ES2-T4 SI DIODE 1SS133
177 O D312 11ES2-T4 SI DIODE 1SS133
178 O D313 11ES2-T4 SI DIODE 1SS133
179 O D314 11ES2-T4 SI DIODE 1SS133
180 O D321 11ES2-T4 SI DIODE 1SS133
181 O D322 11ES2-T4 SI DIODE 1SS133
182 O D323 31N40011 SI DIODE 1N4001
183 O D324 11ES2-T4 SI DIODE 1SS133
184 O D328 11ES2-T4 SI DIODE 1SS133
185 O D329 NIL NM
186 O D330 NIL NM
187 ! O D901 3RS402M1 BRIDGE DIODE RS402M
188 ! O D902 31N40011 SI DIODE 1N4001
189 ! O D903 31N40011 SI DIODE 1N4001
190 ! O D904 31N40011 SI DIODE 1N4001
191 ! O D905 31N40011 SI DIODE 1N4001
192 O D906 31N40011 SI DIODE 1N4001
193 O D907 MTZJ33C-T77 Z DIODE MTZJ33C
194 O D908 MTZ6.2JB Z DIODE MTZJ6.2B
195 O D909 11ES2-T4 SI DIODE 1SS133
196 O D910 MTZ6.2JB Z DIODE MTZJ6.2B
197 O D911 3MTZJ5.6AM0007 Z DIODE MTZJ5.6A
198 O D912 MTZJ12C Z DIODE MTZJ12C
199 O D913 3MTZJ11BM0007 Z DIODE MTZJ11B
200 O D915 MTZJ6.8B Z DIODE MTZJ6.8B
201 O W1051 12P50110 FLAT CABLE ASSY 5P 2.5mm
202 O W951 12S90023 CONNECTOR 9P 2.5mm
203 O FH951 201196010101 FUSE HOLDER 1P 5mm
204 O FH952 201196010101 FUSE HOLDER 1P 5mm
205 O J1053 23B0112 MINI JACK MSJ-2000
206 ! O IC101 TDA7295 IC TDA7295
207 O IC102 113241 IC BA1521B
208 O IC103 113231 IC TDA7440D
209 ! O IC201 TDA7295 IC TDA7295
210 O IC401 TA8189N IC TA8189
211 O IC402 113221 IC 74HC4094
212 O J303 23F0251 SP 4P TERMINAL MSP-103V-04
213 O D75 NIL JUMPER WIRE JW
214 O JA301 23B0931 RCA W/R JACK MSP-242V3
215 O JR1 NRSA63J-0R0X MG RESISTOR 0
216 O JR2 NRSA63J-0R0X MG RESISTOR 0
217 O JR3 NRSA63J-0R0X MG RESISTOR 0
218 O JR4 NRSA63J-0R0X MG RESISTOR 0
219 O JR5 NRSA63J-0R0X MG RESISTOR 0
220 O JR6 NRS181J-0R0X MG RESISTOR 0
221 O JR7 NRSA63J-0R0X MG RESISTOR 0
222 O JR8 NRSA63J-0R0X MG RESISTOR 0
223 O JR9 NRSA63J-0R0X MG RESISTOR 0
224 O JR10 NRSA63J-0R0X MG RESISTOR 0
225 O JR11 NRSA63J-0R0X MG RESISTOR 0
226 O JR12 NRSA63J-0R0X MG RESISTOR 0
227 O JR13 NRSA63J-0R0X MG RESISTOR 0
228 O JR14 NRSA63J-0R0X MG RESISTOR 0
3-26
