JVC MX-K10 - Page 92

 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
229 O JR15 NRS181J-0R0X MG RESISTOR 0
230 O L101 2600702 CHOCK COIL 1uH
231 O L201 2600702 CHOCK COIL 1uH
232 O L301 605071 BIAS-COIL 864306
233 O L302 NIL JUMPER WIRE JW
234 O L303 NIL JUMPER WIRE JW
235 O L304 18A843556N0002 F-BEAD F-B 843556
236 O L305 26100000KM0024 INDUCTOR 10uH
237 O L401 NIL JUMPER WIRE JW
238 O L501 NIL JUMPER WIRE JW
239 O L1051 26047000KM0024 INDUCTOR 4.7uH
240 O L1052 26047000KM0024 INDUCTOR 4.7uH
241 O L1053 18A843556N0002 F-BEAD F-B 843556
242 O Q101 2KTC3199GP0008 TRANSISTOR KTC3199GR
243 O Q103 2KTC3199GP0008 TRANSISTOR KTC3199GR
244 O Q201 2KTC3199GP0008 TRANSISTOR KTC3199GR
245 O Q203 2KTC3199GP0008 TRANSISTOR KTC3199GR
246 O Q301 KRA107M-T D.TRANSISTOR KRA107M
247 O Q302 KTC3200GR TRANSISTOR KTC3200GR
248 O Q303 2KTC3203YP0008 TRANSISTOR KTC3203Y
249 O Q304 2KTA1267GP0008 TRANSISTOR KTA1267GR
250 O Q305 DTC144ESTP D.TRANSISTOR DTC144ES
251 O Q308 DTC144ESTP D.TRANSISTOR DTC144ES
252 O Q309 KTA1273/Y/-T TRANSISTOR KTA1273Y
253 O Q310 2KTC3199GP0008 TRANSISTOR KTC3199GR
254 O Q311 KTA1273/Y/-T TRANSISTOR KTA1273Y
255 O Q312 2KTC3199GP0008 TRANSISTOR KTC3199GR
256 O Q313 KTA1273/Y/-T TRANSISTOR KTA1273Y
257 O Q314 DTC114YSA-T D.TRANSISTOR DTC114YS
258 O Q315 2KTC3199GP0008 TRANSISTOR KTC3199GR
259 O Q316 2KTC3199GP0008 TRANSISTOR KTC3199GR
260 O Q317 2KTC3199GP0008 TRANSISTOR KTC3199GR
261 O Q318 DTC114YSA-T D.TRANSISTOR DTC114YS
262 O Q319 2KTA1270YP0008 TRANSISTOR KTA1270Y
263 O Q321 DTC114YSA-T D.TRANSISTOR DTC114YS
264 O Q322 KRA107M-T D.TRANSISTOR KRA107M
265 O Q323 KRA107M-T D.TRANSISTOR KRA107M
266 O Q324 KRA107M-T D.TRANSISTOR KRA107M
267 O Q325 DTC114YSA-T D.TRANSISTOR DTC114YS
268 O Q327 2KTA1267GP0008 TRANSISTOR KTA1267GR
269 O Q335 KRA107M-T D.TRANSISTOR KRA107M
270 O Q401 2SD2144S/VW/-T TRANSISTOR 2SD2144S
271 O Q402 2SD2144S/VW/-T TRANSISTOR 2SD2144S
272 O Q403 2KTC3199GP0008 TRANSISTOR KTC3199GR
273 O Q404 2KTC3199GP0008 TRANSISTOR KTC3199GR
274 O Q405 2KTC3199GP0008 TRANSISTOR KTC3199GR
275 O Q501 2SD2144S/VW/-T TRANSISTOR 2SD2144S
276 O Q502 2SD2144S/VW/-T TRANSISTOR 2SD2144S
277 O Q503 2KTC3199GP0008 TRANSISTOR KTC3199GR
278 O Q504 2KTC3199GP0008 TRANSISTOR KTC3199GR
279 O Q505 2KTC3199GP0008 TRANSISTOR KTC3199GR
280 O Q901 2SA934RP0007 TRANSISTOR 2SA934R
281 O Q902 DTC114YSA-T D.TRANSISTOR DTC114YS
282 O Q903 DTC114YSA-T D.TRANSISTOR DTC114YS
283 ! O Q904 2KTB1366Y8 TRANSISTOR KTB1366Y
284 O Q905 2KTC3199GP0008 TRANSISTOR KTC3199GR
285 O Q906 2KTC3199GP0008 TRANSISTOR KTC3199GR
3-27
