 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
286 ! O Q907 2KTB1366Y8 TRANSISTOR KTB1366Y
287 O Q908 2KTA1267GP0008 TRANSISTOR KTA1267GR
288 O Q909 KRA107M-T D.TRANSISTOR KRA107M
289 O Q910 DTC114YSA-T D.TRANSISTOR DTC114YS
290 O Q911 2KTC3199GP0008 TRANSISTOR KTC3199GR
291 O Q912 DTC114YSA-T D.TRANSISTOR DTC114YS
292 O R101 NRSA63J-393X MG RESISTOR 39K
293 O R102 NRSA63J-682X MG RESISTOR 6.8K
294 O R103 NRSA63J-222X MG RESISTOR 2.2K
295 O R104 NRSA63J-222X MG RESISTOR 2.2K
296 O R105 NRSA63J-154X MG RESISTOR 150K
297 O R106 NRSA63J-562X MG RESISTOR 5.6K
298 O R107 NRSA63J-0R0X MG RESISTOR 0
299 O R108 NRSA63J-103X MG RESISTOR 10K
300 O R109 NRSA63J-122X MG RESISTOR 1.2K
301 O R110 NRSA63J-222X MG RESISTOR 2.2K
302 O R111 NRSA63J-222X MG RESISTOR 2.2K
303 O R112 NRSA63J-562X MG RESISTOR 5.6K
304 O R113 NRSA63J-103X MG RESISTOR 10K
305 O R114 NRSA63J-102X MG RESISTOR 1K
306 O R115 NRSA63J-223X MG RESISTOR 22K
307 O R116 NRSA63J-563X MG RESISTOR 56K
308 O R117 NRSA63J-222X MG RESISTOR 2.2K
309 O R118 NRSA63J-472X MG RESISTOR 4.7K
310 O R119 NRSA63J-103X MG RESISTOR 10K
311 O R120 NRSA63J-272X MG RESISTOR 2.7K
312 O R121 NRSA63J-563X MG RESISTOR 56K
313 O R122 NRSA63J-122X MG RESISTOR 1.2K
314 O R123 NRSA63J-102X MG RESISTOR 1K
315 O R124 NRSA63J-0R0X MG RESISTOR 0
316 O R125 NRSA63J-102X MG RESISTOR 1K
317 O R128 NRSA63J-220X MG RESISTOR 22
318 O R129 NRSA63J-220X MG RESISTOR 22
319 O R130 NRSA63J-220X MG RESISTOR 22
320 O R131 NRSA63J-103X MG RESISTOR 10K
321 O R138 QRE141J-681 C RESISTOR 680
322 O R150 NRSA63J-220X MG RESISTOR 22
323 O R201 NRSA63J-393X MG RESISTOR 39K
324 O R202 NRSA63J-682X MG RESISTOR 6.8K
325 O R203 NRSA63J-222X MG RESISTOR 2.2K
326 O R204 NRSA63J-222X MG RESISTOR 2.2K
327 O R205 NRSA63J-154X MG RESISTOR 150K
328 O R206 NRSA63J-562X MG RESISTOR 5.6K
329 O R207 NRSA63J-0R0X MG RESISTOR 0
330 O R208 NRSA63J-103X MG RESISTOR 10K
331 O R209 NRSA63J-122X MG RESISTOR 1.2K
332 O R210 NRSA63J-222X MG RESISTOR 2.2K
333 O R211 NRSA63J-222X MG RESISTOR 2.2K
334 O R212 NRSA63J-562X MG RESISTOR 5.6K
335 O R213 NRSA63J-103X MG RESISTOR 10K
336 O R214 NRSA63J-102X MG RESISTOR 1K
337 O R215 NRSA63J-223X MG RESISTOR 22K
338 O R216 NRSA63J-563X MG RESISTOR 56K
339 O R217 NRSA63J-222X MG RESISTOR 2.2K
340 O R218 NRSA63J-472X MG RESISTOR 4.7K
341 O R219 NRSA63J-103X MG RESISTOR 10K
342 O R220 NRSA63J-272X MG RESISTOR 2.7K
3-28
