JVC MX-K10 - Page 94

 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
343 O R221 NRSA63J-563X MG RESISTOR 56K
344 O R222 NRSA63J-122X MG RESISTOR 1.2K
345 O R223 NRSA63J-102X MG RESISTOR 1K
346 O R224 NRSA63J-0R0X MG RESISTOR 0
347 O R225 NRSA63J-102X MG RESISTOR 1K
348 O R226 NRSA63J-223X MG RESISTOR 22K
349 O R227 NRSA63J-223X MG RESISTOR 22K
350 O R228 NRSA63J-220X MG RESISTOR 22
351 O R229 NRSA63J-220X MG RESISTOR 22
352 O R230 NRSA63J-220X MG RESISTOR 22
353 O R231 NRSA63J-103X MG RESISTOR 10K
354 O R232 NIL NM
355 O R238 QRE141J-681 C RESISTOR 680
356 O R250 NRSA63J-220X MG RESISTOR 22
357 O R301 NRSA63J-102X MG RESISTOR 1K
358 O R303 NRSA63J-102X MG RESISTOR 1K
359 O R304 NRSA63J-331X MG RESISTOR 330
360 O R305 NRSA63J-103X MG RESISTOR 10K
361 O R306 NRSA63J-105X MG RESISTOR 1M
362 O R307 NRSA63J-222X MG RESISTOR 2.2K
363 O R308 NRSA63J-103X MG RESISTOR 10K
364 O R309 NRSA63J-100X MG RESISTOR 10
365 O R310 NRSA02J-390X MG RESISTOR 39
366 O R311 NRSA63J-100X MG RESISTOR 10
367 O R312 NRSA63J-102X MG RESISTOR 1K
368 O R313 NRSA63J-471X MG RESISTOR 470
369 O R314 NRSA63J-474X MG RESISTOR 470K
370 O R316 NRSA63J-103X MG RESISTOR 10K
371 O R317 NRSA63J-472X MG RESISTOR 4.7K
372 O R319 NRSA63J-223X MG RESISTOR 22K
373 O R320 NRSA63J-473X MG RESISTOR 47K
374 O R321 NRSA63J-222X MG RESISTOR 2.2K
375 O R322 NRSA63J-222X MG RESISTOR 2.2K
376 O R323 NRSA63J-222X MG RESISTOR 2.2K
377 O R324 NRSA63J-222X MG RESISTOR 2.2K
378 O R325 NRSA63J-222X MG RESISTOR 2.2K
379 O R327 NRSA63J-103X MG RESISTOR 10K
380 O R328 NRSA63J-103X MG RESISTOR 10K
381 O R329 NRSA63J-223X MG RESISTOR 22K
382 O R330 NRSA63J-473X MG RESISTOR 47K
383 O R331 NRSA63J-332X MG RESISTOR 3.3K
384 O R332 NRSA63J-472X MG RESISTOR 4.7K
385 O R333 NRSA63J-151X MG RESISTOR 150
386 O R334 NRSA63J-332X MG RESISTOR 3.3K
387 O R335 NRSA63J-472X MG RESISTOR 4.7K
388 O R336 NRSA63J-151X MG RESISTOR 150
389 O R337 NRSA63J-332X MG RESISTOR 3.3K
390 O R338 NRSA63J-102X MG RESISTOR 1K
391 O R339 NRSA63J-222X MG RESISTOR 2.2K
392 O R340 NRSA63J-222X MG RESISTOR 2.2K
393 O R341 NRSA63J-222X MG RESISTOR 2.2K
394 O R344 NRSA63J-102X MG RESISTOR 1K
395 O R345 NRSA63J-102X MG RESISTOR 1K
396 O R346 NRSA63J-470X MG RESISTOR 47
397 O R347 NRSA63J-102X MG RESISTOR 1K
398 O R348 NRSA63J-222X MG RESISTOR 2.2K
399 O R349 NRSA63J-221X MG RESISTOR 220
3-29
