JVC MX-KB4 User Manual

1-8 (No.MB196)
3.1.4 Removing the top cover
(See Fig.4 and 5)
(1) Remove six screws C that retain the top cover from the
panel rear of the body.
(2) Remove six screws D that retain the top cover from the two
sides of the body.
(3) Remove the top cover from the body by lifting it toward the
rear.
Fig.4
Fig.5
Top cover
C
CC
Right Front panel assembly
D
D
Left Front panel assembly
D
D
