3-7
Subwoofer
Block No. [M][2][M][M]
Symbol No. Part No. Part Name Description Local
1 CD8919081500200 SUBWOOFER 8919-081500200
2 CD6410081500300 EVA PAD CORD A 6410-081500300(x2)
3 CD6410081500400 EVA PAD CORD B 6410-081500400(x2)
4 CD6828081500100 POWER COVER 6828-081500100
5 CD6828081500200 AMPILIFER COVER 6828-081500200
6 CD6700081500600 FELT-1 6700-081500600
7 CD6700081500300 FELT-3 6700-081500300
8 CD6600081500400 HEATSINK B 6600-081500400
9 CD1214050003000 THERMISTOR NTC 1214-050003000
10 CD3502040143900 HOUSING 3502-040143900
11 CD3502060162500 HOUSING 3502-060162500
12 CD6411081500200 EVA COVER 6411-081500200
13 CD6411081500100 EVA COVER 6411-081500100
14 CD6411081500300 EVA COVER 6411-081500300
15 CD6216081500100 BOARD COVER 6216-081500100(x6)
16 CD6110042500100 SPRING 6110-042500100
17 CD6828081500300 BOTTOM COVER 6828-081500300
18 CD6215081500100 BACK PLATE 6215-081500100
19 CD8028000001000 FAN 8028-000001000
20 CD2902123007060 AC CORD 2902-123007060
20 or CD2902125007230 AC CORD 2902-125007230 A,B,C
21 CD6306081500200 BRACKET 6306-081500200
22 CD6011240100100 SCREW 6011-240100100(x3)
23 CD6013345010100 SCREW 6013-345010100(x4)
24 CD6013230100101 SCREW 6013-230100101(x6)
25 CD6033330060100 SCREW 6033-330060100(x44)
26 CD6013230100101 SCREW 6013-230100101(x4)
27 CD6012230120100 SCREW 6012-230120100(x6)
28 CD2712104030000 FERRITE CORE 2712-104030000
29 CD6013230060120 SCREW 6013-230060120
30 CD5939071000200 PLASTIC WASHER 5939-071000200(x4)
31 CD6600081500300 HEATSINK A 6600-081500300(x2)
32 CD8045000000300 SLILCA GEL SHEET 8045-000000300(x2)
33 CD5939080200100 TRANSISTOR WASHER 5939-080200100(x2)
34 CD6013230060120 SCREW 6013-230060120(x4)
35 CD7130081500101 LABEL 7130-081500101 A,B,C
35 CD7130081500200 LABEL 7130-081500200 D
