JVC NX-T10E - Page 46

3-8
Electrical parts list
Display board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
U401 CD1507742126010 IC 1507-742126010
Q401 CD1422080500020 TRANSISTOR 1422-080500020
Q402 CD1422080500020 TRANSISTOR 1422-080500020
Q403 CD1422080500020 TRANSISTOR 1422-080500020
Q404 CD1422080500020 TRANSISTOR 1422-080500020
Q405 CD1422080500020 TRANSISTOR 1422-080500020
Q406 CD1422080500020 TRANSISTOR 1422-080500020
Q407 CD1422080500020 TRANSISTOR 1422-080500020
Q408 CD1421385500000 TRANSISTOR 1421-385500000
Q409 CD1422080500020 TRANSISTOR 1422-080500020
Q410 CD1421385500000 TRANSISTOR 1421-385500000
Q411 CD1411385500000 TRANSISTOR 1411-385500000
Q412 CD1422080500020 TRANSISTOR 1422-080500020
Q413 CD1412080500000 TRANSISTOR 1412-080500000
Q414 CD1422080500020 TRANSISTOR 1422-080500020
Q415 CD1422817400010 TRANSISTOR 1422-817400010
Q416 CD1422817400010 TRANSISTOR 1422-817400010
Q417 CD1421385500000 TRANSISTOR 1421-385500000
Q418 CD1422080500020 TRANSISTOR 1422-080500020
Q419 CD1422080500020 TRANSISTOR 1422-080500020
Q420 CD1421385500000 TRANSISTOR 1421-385500000
Q421 CD1422080500020 TRANSISTOR 1422-080500020
Q422 CD1422080500020 TRANSISTOR 1422-080500020
Q423 CD1422080500020 TRANSISTOR 1422-080500020
Q424 CD1412080500000 TRANSISTOR 1412-080500000
Q425 CD1421385500000 TRANSISTOR 1421-385500000
Q426 CD1422080500020 TRANSISTOR 1422-080500020
Q427 CD1422080500020 TRANSISTOR 1422-080500020
Q428 CD1421385500000 TRANSISTOR 1421-385500000
Q429 CD1422080500020 TRANSISTOR 1422-080500020
Q430 CD1422080500020 TRANSISTOR 1422-080500020
D401 CD1321041480050 DIODE 1321-041480050
D402 CD1321041480050 DIODE 1321-041480050
D403 CD1321041480050 DIODE 1321-041480050
D404 CD1322005200020 BARRIER DIODE 1322-005200020
D405 CD1322005200020 BARRIER DIODE 1322-005200020
D406 CD1321041480050 DIODE 1321-041480050
D407 CD1322005200020 BARRIER DIODE 1322-005200020
D408 CD1322005200020 BARRIER DIODE 1322-005200020
C401 CD1121104082020 C CAPACITOR 1121-104082020
C402 CD1121104082020 C CAPACITOR 1121-104082020
C403 CD1121222082020 C CAPACITOR 1121-222082020
C404 CD1121222082020 C CAPACITOR 1121-222082020
C405 CD1121106042170 C CAPACITOR 1121-106042170
C406 CD1121104082020 C CAPACITOR 1121-104082020
C407 CD1121104082020 C CAPACITOR 1121-104082020
C408 CD1121104082020 C CAPACITOR 1121-104082020
C409 CD1121104082020 C CAPACITOR 1121-104082020
C411 CD1121104082020 C CAPACITOR 1121-104082020
C412 CD1121104082020 C CAPACITOR 1121-104082020
C413 CD1121104082020 C CAPACITOR 1121-104082020
R401 CD1221272062020 C RESISTOR 1221-272062020
R403 CD1221103062020 C RESISTOR 1221-103062020
R404 CD1221472062020 C RESISTOR 1221-472062020
R405 CD1221473062020 C RESISTOR 1221-473062020
R406 CD1221243062020 C RESISTOR 1221-243062020
R407 CD1221103062020 C RESISTOR 1221-103062020
R408 CD1221103062020 C RESISTOR 1221-103062020
R409 CD1221511062020 C RESISTOR 1221-511062020
R410 CD1221103062020 C RESISTOR 1221-103062020
R411 CD1221103062020 C RESISTOR 1221-103062020
R412 CD1221103062020 C RESISTOR 1221-103062020
R413 CD1221103062020 C RESISTOR 1221-103062020
R414 CD1221470062020 C RESISTOR 1221-470062020
R415 CD1221470062020 C RESISTOR 1221-470062020
R416 CD1221103062020 C RESISTOR 1221-103062020
R417 CD1221103062020 C RESISTOR 1221-103062020
R418 CD1221103062020 C RESISTOR 1221-103062020
R419 CD1221102062020 C RESISTOR 1221-102062020
R420 CD1221103062020 C RESISTOR 1221-103062020
R421 CD1221102062020 C RESISTOR 1221-102062020
R423 CD1221103062020 C RESISTOR 1221-103062020
R424 CD1221152062020 C RESISTOR 1221-152062020
R425 CD1221102062020 C RESISTOR 1221-102062020
R426 CD1221563062020 C RESISTOR 1221-563062020
R427 CD1221102062020 C RESISTOR 1221-102062020
R428 CD1221272062020 C RESISTOR 1221-272062020
R429 CD1221472062020 C RESISTOR 1221-472062020
R430 CD1221103062020 C RESISTOR 1221-103062020
R431 CD1221103062020 C RESISTOR 1221-103062020
R432 CD1221563062020 C RESISTOR 1221-563062020
R433 CD1221103062020 C RESISTOR 1221-103062020
R434 CD1221103062020 C RESISTOR 1221-103062020
R435 CD1221184062020 C RESISTOR 1221-184062020
R436 CD1221103062020 C RESISTOR 1221-103062020
R437 CD1221184062020 C RESISTOR 1221-184062020
R438 CD1221103062020 C RESISTOR 1221-103062020
R439 CD1221103062020 C RESISTOR 1221-103062020
R440 CD1221303062020 C RESISTOR 1221-303062020
R441 CD1221103062020 C RESISTOR 1221-103062020
R442 CD1221103062020 C RESISTOR 1221-103062020
R443 CD1221101062020 C RESISTOR 1221-101062020
R444 CD1221104062020 C RESISTOR 1221-104062020
R445 CD1221333062020 C RESISTOR 1221-333062020
R446 CD1221101062020 C RESISTOR 1221-101062020
R447 CD1221104062020 C RESISTOR 1221-104062020
R448 CD1221333062020 C RESISTOR 1221-333062020
R449 CD1221102062020 C RESISTOR 1221-102062020
R450 CD1221622062020 C RESISTOR 1221-622062020
R451 CD1221332062020 C RESISTOR 1221-332062020
R452 CD1221152062020 C RESISTOR 1221-152062020
R453 CD1221152062020 C RESISTOR 1221-152062020
R454 CD1221103062020 C RESISTOR 1221-103062020
R455 CD1221102062020 C RESISTOR 1221-102062020
R456 CD1221563062020 C RESISTOR 1221-563062020
R457 CD1221563062020 C RESISTOR 1221-563062020
R458 CD1221102062020 C RESISTOR 1221-102062020
R459 CD1221222062020 C RESISTOR 1221-222062020
R460 CD1221103062020 C RESISTOR 1221-103062020
R461 CD1221103062020 C RESISTOR 1221-103062020
R462 CD1211471012000 RESISTOR 1211-471012000
R464 CD1221102062020 C RESISTOR 1221-102062020
R465 CD1221103062020 C RESISTOR 1221-103062020
R466 CD1221103062020 C RESISTOR 1221-103062020
R467 CD1221103062020 C RESISTOR 1221-103062020
R468 CD1221473062020 C RESISTOR 1221-473062020
R469 CD1221103062020 C RESISTOR 1221-103062020
R470 CD1221103062020 C RESISTOR 1221-103062020
R471 CD1221103062020 C RESISTOR 1221-103062020
R472 CD1221152062020 C RESISTOR 1221-152062020
R473 CD1221102062020 C RESISTOR 1221-102062020
R474 CD1221103062020 C RESISTOR 1221-103062020
R475 CD1221102062020 C RESISTOR 1221-102062020
R476 CD1221103062020 C RESISTOR 1221-103062020
R477 CD1221103062020 C RESISTOR 1221-103062020
R478 CD1221103062020 C RESISTOR 1221-103062020
R479 CD1221000062020 C RESISTOR 1221-000062020
R481 CD1221102062020 C RESISTOR 1221-102062020
R482 CD1221102062020 C RESISTOR 1221-102062020
R483 CD1221000062020 C RESISTOR 1221-000062020
R484 CD1221000062020 C RESISTOR 1221-000062020
R491 CD1221000062020 C RESISTOR 1221-000062020
CON401 CD3106101911000 FFC CONNECTOR 3106-101911000
CON402 CD3106100520000 FFC CONNECTOR 3106-100520000
CON403 CD3106100520000 FFC CONNECTOR 3106-100520000
EC402 CD1132106053010 E CAPACITOR 1132-106053010
EC403 CD1132476053040 E CAPACITOR 1132-476053040
EC404 CD1132476053040 E CAPACITOR 1132-476053040
EC407 CD1132476053040 E CAPACITOR 1132-476053040
EC408 CD1132106083080 E CAPACITOR 1132-106083080
EC409 CD1132476073200 E CAPACITOR 1132-476073200
EC410 CD1112108043291 E CAPACITOR 1112-108043291
 Symbol No. Part No. Part Name Description Local
