ENGLISH
12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Default:
XX
EQ SETTING
PRESET EQ
Select a preset equalizer suitable to the music genre.
•
Select
[USER]
to use the settings made in
[EASY EQ]
or
[PRO EQ]
.
FLAT
/
DRVN 3
/
DRVN 2
/
DRVN 1
/
HARD ROCK
/
HIP HOP
/
JAZZ
/
POP
/
R&B
/
TALK
/
USER
/
VOCAL BOOST
/
BASS BOOST
/
CLASSICAL
/
DANCE
EASY EQ
Adjust your own sound settings.
•
The settings are stored to
[USER]
.
•
The settings made may affect the current settings of
[PRO EQ]
.
SUB.W SP
*
1
*
2
:
00
to
+06
(Default:
03
SUB.W
*
1
*
3
:
–08
to
+08
00
BASS
:
LVL–06
to
LVL+06
LVL 00
MID
:
LVL–06
to
LVL+06
LVL 00
TRE
:
LVL–06
to
LVL+06
LVL 00
)
PRO EQ
1
BASS
/
MIDDLE
/
TREBLE
:Select a sound tone.
2
Adjust the sound elements of the selected sound tone.
•
The settings are stored to
[USER]
.
•
The settings made may affect the current settings of
[EASY EQ]
.
BASS
Frequency:
60HZ
/
80HZ
/
100HZ
/
200HZ
(Default:
80HZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q1.0
/
Q1.25
/
Q1.5
/
Q2.0
Q1.0
)
MIDDLE
Frequency:
0.5KHZ
/
1.0KHZ
/
1.5KHZ
/
2.5KHZ
(Default:
1.0KHZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q0.75
/
Q1.0
/
Q1.25
Q1.25
)
TREBLE
Frequency:
10.0KHZ
/
12.5KHZ
/
15.0KHZ
/
17.5KHZ
(Default:
10.0KHZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q FIX
Q FIX
)
AUDIO CONTROL
BASS BOOST
LEVEL +01
to
LEVEL +05
(
LEVEL +01
): Selects your preferred bass boost level.;
OFF
:Cancels.
LOUDNESS LEVEL 01
/
LEVEL 02
:Boosts low or high frequencies to produce a well-balanced
sound at low volume.;
OFF
:Cancels.
AUDIO SETTINGS
SUB.W LEVEL
*
1
SPK-OUT
*
2
SUB.W 00
to
SUB.W +06
(
SUB.W +03
):Adjusts
the output level of the subwoofer connected via
speaker lead.
( 19)
PRE-OUT
*
3
SUB.W –08
to
SUB.W +08
(
SUB.W 00
):Adjusts
the output level of the subwoofer connected to the
lineout terminals (REAR/SW) through an external
amplifier.
( 19)
SUBWOOFER SET
*
3
ON
: Turns on the subwoofer output.;
OFF
: Cancels.
SUBWOOFER
LPF
*
1
FRQ THROUGH
:All signals are sent to the subwoofer;
FRQ 55HZ
/
FRQ 85HZ
/
FRQ 120HZ
:Audio signals with frequencies
lower than 55Hz/85Hz/120Hz are sent to the subwoofer.
SUB.W PHASE
*
1
*
4
REVERSE
(180°)/
NORMAL
(0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum
performance.
FADER POSITION R06
to
POSITION F06
(
POSITION 00
):Adjusts the front
and rear speaker output balance.
BALANCE
*
5
POSITION L06
to
POSITION R06
(
POSITION 00
):Adjusts the left
and right speaker output balance.
VOLUME
ADJUST LEVEL –15
to
LEVEL +06
(
LEVEL 00
):Preset the initial volume
level of each source (compared to the FM volume level). Before
adjustment, select the source you want to adjust. (“VOLADJFIX”
appears if FM is selected.)
AMP
GAIN LOW POWER
:Limits the maximum volume level to 25. (Select if
the maximum power of each speaker is less than 50W to prevent
damaging the speakers.);
HIGH POWER
:The maximum volume
level is 35.
*
1
Displayed only when
[SUBWOOFER SET]
is set to
[ON]
.
*
2
Displayed only when
[SPK/PRE OUT]
is set to
[SUB.W/SUB.W]
.
( 13)
*
3
Displayed only when
[SPK/PRE OUT]
is set to
[REAR/SUB.W]
or
[SUB.W/SUB.W]
.
( 13)
*
4
Selectable only if a setting other than
[FRQ THROUGH]
is selected for
[SUBWOOFER LPF]
.
*
5
This adjustment will not affect the subwoofer output.
