EQ SETTING
PRESET EQ
.ﺪﻨﻛ ﯽﻣ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﯽﻘﻴﺳﻮﻣ ﺮﻧﺍژ ﺎﺑ ﺐﺳﺎﻨﺘﻣ ﻢﻴﻈﻨﺗ ﺶﻴﭘ ﺭﺰﻳﻻﻮﻛﺍ ﮏﻳ
ﺍﺭ
[USER] ،ﺪﻳﺍ ﻩﺩﺍﺩ ﻡﺎﺠﻧﺍ [PRO EQ] ﺎﻳ [EASY EQ] ﺭﺩ ﻪﻛ ﯽﺗﺎﻤﻴﻈﻨﺗ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ یﺍﺮﺑ •
.ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ
/
R&B / POP / JAZZ / HIP HOP / HARD ROCK / DRVN 1 / DRVN 2 / DRVN 3 / FLAT
DANCE
/ CLASSICAL / BASS BOOST / VOCAL BOOST / USER / TALK
EASY EQ
.ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺍﺭ ﺩﻮﺧ یﺍﺪﺻ ﺕﺎﻤﻴﻈﻨﺗ
.ﺖﺳﺍ ﻩﺪﺷ ﻩﺮﻴﺧﺫ
[USER] یﻭﺭ ﺕﺎﻤﻴﻈﻨﺗ ﻦﻳﺍ •
.ﺩﺭﺍﺬﮕﺑ ﺮﻴﺛﺄﺗ
[PRO EQ] ﯽﻠﻌﻓ ﺕﺎﻤﻴﻈﻨﺗ ﺮﺑ ﻩﺪﺷ ﻡﺎﺠﻧﺍ ﺕﺎﻤﻴﻈﻨﺗ ﺖﺳﺍ ﻦﻜﻤﻣ •
03 : ﺽﺮﻓ ﺶﻴﭘ) +06 ﺎﺗ 00 : SUB.W SP
*
1
*
2
00 +08 ﺎﺗ –08 : SUB.W
*
1
*
3
LVL 00 LVL+06 ﺎﺗ LVL–06 : BASS
LVL 00 LVL+06
ﺎﺗ LVL–06 : MID
( LVL 00 LVL+06 ﺎﺗ LVL–06 : TRE
PRO EQ
.ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﺍﺪﺻ ﮏﻳ : TREBLE / MIDDLE / BASS 1
.ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺍﺭ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ یﺍﺪﺻ ﻪﺑ ﻁﻮﺑﺮﻣ یﺎﻫ ﺖﻤﺴﻗ 2
.ﺖﺳﺍ ﻩﺪﺷ ﻩﺮﻴﺧﺫ
[USER] یﻭﺭ ﺕﺎﻤﻴﻈﻨﺗ ﻦﻳﺍ •
.ﺩﺭﺍﺬﮕﺑ ﺮﻴﺛﺄﺗ
[EASY EQ] ﯽﻠﻌﻓ ﺕﺎﻤﻴﻈﻨﺗ ﺮﺑ ﻩﺪﺷ ﻡﺎﺠﻧﺍ ﺕﺎﻤﻴﻈﻨﺗ ﺖﺳﺍ ﻦﻜﻤﻣ •
80HZ : ﺽﺮﻓ ﺶﻴﭘ) 200HZ / 100HZ / 80HZ / 60HZ : ﺲﻧﺎﻛﺮﻓ BASS
LVL 00 LVL+06
ﺎﺗ LVL–06 : ﺢﻄﺳ
(
Q1.0 Q2.0 / Q1.5 / Q1.25 / Q1.0 : Q
1.0KHZ : ﺽﺮﻓ ﺶﻴﭘ) 2.5KHZ / 1.5KHZ / 1.0KHZ / 0.5KHZ : ﺲﻧﺎﻛﺮﻓ MIDDLE
LVL 00 LVL+06
ﺎﺗ LVL–06 : ﺢﻄﺳ
(
Q1.25 Q1.25 / Q1.0 / Q0.75 : Q
10.0KHZ : ﺽﺮﻓ ﺶﻴﭘ) 17.5KHZ / 15.0KHZ / 12.5KHZ / 10.0KHZ : ﺲﻧﺎﻛﺮﻓ TREBLE
LVL 00 LVL+06
ﺎﺗ LVL–06 : ﺢﻄﺳ
(
Q FIX Q FIX : Q
AUDIO CONTROL
BASS BOOST
ﺎﻤﺷ ﻩﺍﻮﺨﻟﺩ ﺩﺭﻮﻣ ﺱﺎﺑ یﺍﺪﺻ ﺖﻳﻮﻘﺗ ﺢﻄﺳ :( LEVEL +01 ) LEVEL +05 ﺎﺗ LEVEL +01
.ﺩﻮﺷ ﻰﻣ ﻮﻐﻟ : OFF ؛ .ﺪﻨﻛ ﯽﻣ ﺏﺎﺨﺘﻧﺍ ﺍﺭ
LOUDNESS ﺭﺩ ﻲﻟﺎﻋ ﺖﻴﻔﻴﻛ ﺎﺑ ﯽﻳﺍﺪﺻ ،￯ﻮﻗ ﺎﻳ ﻒﻴﻌﺿ ￯ﺎﻫ ﺲﻧﺎﻛﺮﻓ ﺖﻳﻮﻘﺗ ﺎﺑ : LEVEL 02 / LEVEL 01
.ﺩﻮﺷ ﻰﻣ ﻮﻐﻟ : OFF ؛ .ﺪﻨﻛ ﯽﻣ ﺪﻴﻟﻮﺗ ﻢﻳﻼﻣ ﺢﻄﺳ
ﺍﺪﺻ ﺕﺎﻤﻴﻈﻨﺗ
SUB.W LEVEL
*
1
SPK-OUT
*
2
ﻥﺍﺰﻴﻣ :( SUB.W +03 ) SUB.W +06 ﺎﺗ SUB.W 00
ﻞﺼﺘﻣ ﻮﮔﺪﻨﻠﺑ ﻢﻴﺳ ﻖﻳﺮﻃ ﺯﺍ ﻪﻛ یﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
(19 ) .ﺪﻨﻛ ﯽﻣ ﻢﻴﻈﻨﺗ ﺍﺭ ﺖﺳﺍ ﻩﺪﺷ
PRE-OUT
*
3
ﻥﺍﺰﻴﻣ :( SUB.W 00 ) SUB.W +08 ﺎﺗ SUB.W –08
ﻪﻧﺎﻳﺎﭘ ﻪﺑ ﺮﻳﺎﻓ ﯽﻠﭙﻣﺁ ﮏﻳ ﻖﻳﺮﻃ ﺯﺍ ﻪﻛ یﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
ﻢﻴﻈﻨﺗ ﺍﺭ ﺖﺳﺍ ﻩﺪﺷ ﻞﺼﺘﻣ (REAR/SW) ﯽﺟﻭﺮﺧ یﺎﻫ
(19 ) .ﺪﻨﻛ ﯽﻣ
SUBWOOFER SET
*
3
.ﺩﻮﺷ ﻰﻣ ﻮﻐﻟ : OFF ؛ .ﺪﻨﻛ ﯽﻣ ﻦﺷﻭﺭ ﺍﺭ ﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ : ON
SUBWOOFER LPF
*
1
؛ ﺪﻧﻮﺷ ﯽﻣ ﻝﺎﺳﺭﺍ ﺮﻓﻭﻭ ﺏﺎﺳ ﻖﻳﺮﻃ ﺯﺍ ﺎﻬﻟﺎﮕﻨﻴﺳ ﻪﻴﻤﻫ : FRQ THROUGH
ﺲﻧﺎﻛﺮﻓ ﺎﺑ ﯽﺗﻮﺻ یﺎﻫ ﻝﺎﻨﮕﻴﺳ : FRQ 120HZ / FRQ 85HZ / FRQ 55HZ
.ﺪﻧﻮﺷ ﯽﻣ ﻩﺩﺎﺘﺳﺮﻓ ﺮﻓﻭﻭ ﺏﺎﺳ ﻪﺑ ﺰﺗﺮﻫ 120/ﺰﺗﺮﻫ 85/ﺰﺗﺮﻫ 55 ﺯﺍ ﺮﺘﻤﻛ یﺎﻫ
SUB.W PHASE
*
1
*
4
ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﺮﻓﻭﻮﺑﺎﺳ ﯽﺟﻭﺮﺧ ﻪﻠﺣﺮﻣ :(0°) NORMAL /(180°) REVERSE
.ﺩﻮﺷ ﻪﺋﺍﺭﺍ ﺩﺮﻜﻠﻤﻋ ﻦﻳﺮﺘﻬﺑ ﻭ ﺪﺷﺎﺑ ﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ ﺎﺑ ﻡﺎﮕﻤﻫ ﺎﺗ ﺪﻨﻛ ﯽﻣ
FADER ﯽﺟﻭﺮﺧ ﺲﻧﻻﺎﺑ :( POSITION 00 ) POSITION F06 ﺎﺗ POSITION R06
.ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺍﺭ ﻰﺘﺸﭘ ﻭ ﻰﻳﻮﻠﺟ ￯ﻮﮔﺪﻨﻠﺑ
BALANCE
*
5
ﯽﺟﻭﺮﺧ ﺲﻧﻻﺎﺑ :( POSITION 00 ) POSITION R06 ﺎﺗ POSITION L06
.ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺍﺭ ﺖﺳﺍﺭ ﻭ ﭗﭼ ￯ﻮﮔﺪﻨﻠﺑ
VOLUME ADJUST ﺭﺩ) ﻊﺒﻨﻣ ﺮﻫ یﺍﺪﺻ ﻪﻴﻟﻭﺍ ﺢﻄﺳ :( LEVEL 00 ) LEVEL +06 ﺎﺗ LEVEL –15
ﻪﻛ ﻊﺒﻨﻣ ،ﻢﻴﻈﻨﺗ ﺯﺍ ﻞﺒﻗ .ﺪﻨﻛ ﯽﻣ ﻢﻴﻈﻨﺗ ﺶﻴﭘ ﺯﺍ ﺍﺭ (FM ﻡﻮﻟﻭ ﺢﻄﺳ ﺎﺑ ﻪﺴﻳﺎﻘﻣ
ﻪﻨﻳﺰﮔ ،FM ﺏﺎﺨﺘﻧﺍ ﺕﺭﻮﺻ ﺭﺩ) .ﺪﻴﻳﺎﻤﻧ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺪﻴﻫﺍﻮﺧ ﯽﻣ
(.ﺩﻮﺷ ﯽﻣ ﺮﻫﺎﻇ “VOL ADJ FIX”
AMP GAIN .ﺪﻨﻛ ﯽﻣ ﺩﻭﺪﺤﻣ 25 ﻪﺑ ﺍﺭ ﺍﺪﺻ ﻡﻮﻟﻭ ﻥﺍﺰﻴﻣ ﺮﺜﻛﺍﺪﺣ : LOW POWER
یﺍﺮﺑ ،ﺖﺳﺍ ﺕﺍﻭ 50 ﺯﺍ ﺮﺘﻤﻛ ﺎﻫﻮﮔﺪﻨﻠﺑ ﺯﺍ ﮏﻳ ﺮﻫ ﻥﺍﻮﺗ ﺮﺜﻛﺍﺪﺣ ﺮﮔﺍ)
؛ (.ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﻪﻨﻳﺰﮔ ﻦﻳﺍ ﺎﻫﻮﮔﺪﻨﻠﺑ ﻥﺪﻳﺩ ﺐﻴﺳﺁ ﺯﺍ یﺮﻴﮔﻮﻠﺟ
.ﺖﺳﺍ 35 ﺍﺪﺻ ﻡﻮﻟﻭ ﻥﺍﺰﻴﻣ ﺮﺜﻛﺍﺪﺣ :
HIGH POWER
.ﺩﻮﺷ ﯽﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ،ﺪﺷﺎﺑ ﻩﺪﺷ ﻢﻴﻈﻨﺗ [ON] یﻭﺭ [SUBWOOFER SET] ﯽﺘﻗﻭ ﻂﻘﻓ
*
1
.ﺩﻮﺷ ﻰﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ﺪﺷﺎﺑ ﻩﺪﺷ ﻢﻴﻈﻨﺗ [SUB.W/SUB.W] ￯ﻭﺭ ﺮﺑ [SPK/PRE OUT] ﻰﺘﻗﻭ ﻂﻘﻓ
*
2
(13 )
ﺪﺷﺎﺑ ﻩﺪﺷ ﻢﻴﻈﻨﺗ [SUB.W/SUB.W] ﺎﻳ [REAR/SUB.W] ￯ﻭﺭ ﺮﺑ [SPK/PRE OUT] ﻰﺘﻗﻭ ﻂﻘﻓ
*
3
(13 ) .ﺩﻮﺷ ﻰﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ
[SUBWOOFER LPF] یﺍﺮﺑ [FRQ THROUGH] ﺰﺠﺑ ﯽﻤﻴﻈﻨﺗ ﻪﻛ ﺖﺳﺍ ﺏﺎﺨﺘﻧﺍ ﻞﺑﺎﻗ ﯽﻧﺎﻣﺯ ﻂﻘﻓ
*
4
.ﺪﺷﺎﺑ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ
.ﺩﺭﺍﺬﮕﺑ ﺮﺛﺍ ﺮﻓﻭﻭ ﺏﺎﺳ ￯ﻭﺭ ﺮﺑ ﺪﻧﺍﻮﺗ ﻰﻤﻧ ﻢﻴﻈﻨﺗ
*
5
