15
External Connection
Connecting PC
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
5.1 CH audio is possible when the TV is connected to an external device supporting 5.1 CH.
Supporting Signals
Input
Input Resolution
Vertical
Frequency
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
720p
1080i
1080p
24Hz/25Hz/30Hz/60Hz
3840x2160
HDMI
Digital
Analog
CVBS
Mode
ATSC
NTSC
NTSC
Connect an OPTICAL Cable between the OPTICAL jacks on the TV and the Digital Audio Input jacks
on the Digital Audio System. When a Digital Audio System is connected to the OPTICAL terminal:
Decrease the gain (volume) of the tv, and adjust the volume level with the Digital Audio System’s
volume control.
AUDIO Receiver(Not included)
(Back)
Digital Audio System
