1-2 (No.MB105)
SPECIFICATION
Designs & specifications are subject to change without notice.
Amplifier
Output Power
At stereo operation Front channels 100 W per channel*, min. RMS, driven into 8 Ω at 1 kHz with no more
than 0.8% total harmonic distortion. (IEC268-3)
At surround operation Front channels 100 W per channel*, min. RMS, driven into 8 Ω at 1 kHz with no more
than 0.8% total harmonic distortion.
Center channel 100 W*, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8%
total harmonic distortion.
Surround channels 100 W per channel*, min. RMS, driven into 8 Ω at 1 kHz, with no more
than 0.8% total harmonic distortion.
*Measured on AC 110V, 127 V, 220 V and 240 V.
Audio
Audio Input Sensitivity/Impedance (1 kHz) DVD, DVD MULTI, DBS, VCR, TV:260 mV/47 kΩ
Audio Input (DIGITAL IN)* Coaxial DIGITAL 1 (DVD):0.5 V(p-p)/75 Ω
Optical DIGITAL 2/3 (DBS/TV):-21 dBm to -15 dBm(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency-32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level VCR:250 mV
Signal-to-Noise Ratio
('66 IHF/DIN)
DVD MULTI:87 dB/62 dB
Frequency Response (8 Ω) DVD, DBS, VCR, TV:20 Hz to 20 kHz (±1 dB)
Tone Control Bass (100 Hz):±10 dB ±2 dB
Treble (10 kHz):±10 dB ±2 dB
Bass Boost +4 dB ± 1 dB at 100 Hz
Video
Video Input Sensitivity
/Impedance (1 kHz)
Composite video:DVD, DBS, VCR 1 V(p-p)/75 Ω
S-Video:DVD, DBS, VCR (Y:luminance):1 V(p-p)/75 Ω
(C:chrominance):0.286 V(p-p)/75 Ω
Component video:DVD, DBS (Y:luminance):1 V(p-p)/75 Ω
(PB/PR):0.7 V(p-p)/75 Ω
Video Input Sensitivity/
Impedance (1 kHz)
Composite video:VCR, MONITOR OUT 1 V(p-p)/75 Ω
S-Video:VCR, MONITOR OUT (Y:luminance):1 V(p-p)/75 Ω
(C:chrominance):0.286 V(p-p)/75 Ω
Component video:MONITOR OUT (Y:luminance):1 V(p-p)/75 Ω
(PB/PR):0.7 V(p-p)/75 Ω
Synchronize Negative
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity Monaural 16.0 dBf (1.7 µV/75 Ω)
Stereo 37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at REC OUT: 35 dB at 1 kHz
AM tuner
Tuning Range 522 kHz to 1 629 kHz
General
Power Requirements AC 110 V/127 V/220 V/230 V-240 V, adjustable with the voltage selector, 50 Hz/60 Hz
Power Consumption 100 W (at operation), 5 W (in standby mode)
Dimensions (W × H × D) 435 mm × 69.5 mm × 330.5 mm
Mass 6.5 kg
