JVC RX-ES1SL - Page 45

3-13
Input board
Block No. [0][3][0][0]
L701 QQL28AK-221 CHOKE COIL 220uH K
L1301 QQL67AM-220 COIL 22uH M
L1302 QQL67AM-220 COIL 22uH M
L1303 QQL67AM-220 COIL 22uH M
L1304 QQL67AM-220 COIL 22uH M
L1801 QQL67AM-220 COIL 22uH M
L1802 QQL67AM-220 COIL 22uH M
L1803 QQL67AM-220 COIL 22uH M
L1804 QQL67AM-220 COIL 22uH M
L1901 QQL67AM-220 COIL 22uH M
L1903 QQL67AM-220 COIL 22uH M
CN301 QGB1214J3-18S CONNECTOR B-B (1-18)
CN302 QGB1214J3-18S CONNECTOR B-B (1-18)
CN516 QGA2501C1-08 CONNECTOR W-B (1-8)
CN519 QGA2501C1-09 CONNECTOR W-B (1-9)
CN521 QGB2510J1-10 CONNECTOR B-B (1-10)
CN522 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN702 QGA3901C1-03 CONNECTOR W-B (1-3)
CN703 QGA2501C1-03 CONNECTOR W-B (1-3)
CN712 QGD2501C1-03Z CONNECTOR (1-3)
CN713 QJK019-030703 SIN CR C-B WIRE
CN725 QJK025-060801 SIN CR C-B WIRE
CN801 QGB1214J3-18S CONNECTOR B-B (1-18)
CN802 QGB1214J3-18S CONNECTOR B-B (1-18)
CN901 QGB1214J3-18S CONNECTOR B-B (1-18)
EP701 QNZ0136-001Z EARTH PLATE
EP711 QNZ0136-001Z EARTH PLATE
FS707 VYSH101-009 SPACER
FS865 VYSH101-009 SPACER
FW701 QUM213-08DGZ3 PARA RIBON WIRE
HS701 E70306-001 HEAT SINK
HS722 E70306-001 HEAT SINK
J601 QNN0347-001 SURROUND JACK
K601 NQR0269-004X FERRITE BEADS
 RY301 QSK0127-001 RELAY
 RY701 QSK0127-002 RELAY
 RY801 QSK0127-001 RELAY
 RY901 QSK0127-001 RELAY
 ST701 QNB0184-001 SPEAKER TERMINA
UN661 GP1FA352RZ OPT RECEIVER
Optical fiber data
kink receive unit
UN662 GP1FA352RZ OPT RECEIVER
Optical fiber data
kink receive unit
X631 QAX0722-001Z CRYSTAL 24.576MHz
X671 QAX0719-001Z C RESONATOR 6.144MHz
X711 QAX0734-001 C RESONATOR 400.00kHz
X712 QAX0735-001 C RESONATOR 420.00kHz
 Symbol No. Part No. Part Name Description Local
IC501 MN101C49GMH IC System control
IC502 BD3842FS-X IC 6ch function switch
IC503 BD3813KS IC 6ch volume IC
IC504 HA17558AF-X IC
Dual Operational
Amp
IC506 IC-PST9139-T IC Regulator
IC521 NJM2246M-X IC
IC522 NJM2246M-X IC
IC523 NJM2246M-X IC
IC531 MM74HC4053SJ-X IC Multiplexer
IC532 NJM2580M-X IC Video amp
IC571 HA17558AF-X IC
Dual Operational
Amp
Q501 2SC3576-JVC-T TRANSISTOR
Q502 2SC3576-JVC-T TRANSISTOR
Q503 KRA104S-X DIGI TRANSISTOR
Q510 KRC102S-X DIGI TRANSISTOR
Q511 KRA104S-X DIGI TRANSISTOR
Q512 KRA104S-X DIGI TRANSISTOR
Q513 2SC3576-JVC-T TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q514 2SC3576-JVC-T TRANSISTOR
Q515 2SC3576-JVC-T TRANSISTOR
Q516 2SC3576-JVC-T TRANSISTOR
Q517 2SC3576-JVC-T TRANSISTOR
Q518 2SC3576-JVC-T TRANSISTOR
Q519 2SC3576-JVC-T TRANSISTOR
Q521 2SC3576-JVC-T TRANSISTOR
Q522 2SC3576-JVC-T TRANSISTOR
Q523 KRA104S-X DIGI TRANSISTOR
Q525 KTC3199/GL/-T TRANSISTOR
Q526 KTC3199/GL/-T TRANSISTOR
Q527 KTC3199/GL/-T TRANSISTOR
 Q531 2SD2395/EF/ TRANTRANSISTOR
Q532 KRA102S-X DIGI TRANSISTOR
Q533 KRC102S-X DIGI TRANSISTOR
Q534 KRC102S-X DIGI TRANSISTOR
Q535 KRC102S-X DIGI TRANSISTOR
Q536 KRC102S-X DIGI TRANSISTOR
Q541 KRA102S-X DIGI TRANSISTOR
Q542 2SB709A/QR/-X TRANSISTOR
Q543 2SB709A/QR/-X TRANSISTOR
Q544 2SB709A/QR/-X TRANSISTOR
Q4501 KTC3199/GL/-T TRANSISTOR
Q4502 KTC3199/GL/-T TRANSISTOR
Q4503 KTC3199/GL/-T TRANSISTOR
Q4504 KRC107S-X DIGI TRANSISTOR
Q4505 KRC107S-X DIGI TRANSISTOR
Q4506 KRC107S-X DIGI TRANSISTOR
Q4507 KTC3199/GL/-T TRANSISTOR
Q4508 KTC3199/GL/-T TRANSISTOR
Q4509 KTC3199/GL/-T TRANSISTOR
Q4510 KRC107S-X DIGI TRANSISTOR
Q4511 KRC107S-X DIGI TRANSISTOR
Q4512 KRC107S-X DIGI TRANSISTOR
Q7503 2SK301/QR/-T FET
Q7504 2SK301/QR/-T FET
D509 MA111-X SI DIODE
D510 MA111-X SI DIODE
D512 UDZS6.2B-X Z DIODE
D515 MA111-X SI DIODE
D516 UDZS13B-X Z DIODE
D517 UDZS10B-X Z DIODE
D518 UDZS7.5B-X Z DIODE
D554 MA111-X SI DIODE
D556 MA111-X SI DIODE
D561 MA111-X SI DIODE
D4501 MA111-X SI DIODE
D4502 MA111-X SI DIODE
D5501 MA111-X SI DIODE
D5502 MA111-X SI DIODE
C231 NCB31HK-562X C CAPACITOR 5600pF 50V K
C232 NCB31HK-562X C CAPACITOR 5600pF 50V K
C233 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C234 NCB31HK-102X C CAPACITOR 1000pF 50V K
C513 NCS31HJ-331X C CAPACITOR 330pF 50V J
C514 NCS31HJ-331X C CAPACITOR 330pF 50V J
C515 NCS31HJ-331X C CAPACITOR 330pF 50V J
C516 NCS31HJ-331X C CAPACITOR 330pF 50V J
C517 NCS31HJ-331X C CAPACITOR 330pF 50V J
C518 NCS31HJ-331X C CAPACITOR 330pF 50V J
C522 NCB31HK-561X C CAPACITOR 560pF 50V K
C523 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C524 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C525 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C526 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C527 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C528 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C529 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C530 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C531 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C532 NCB31HK-561X C CAPACITOR 560pF 50V K
C533 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C534 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C535 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C536 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C537 QETN1HM-106Z E CAPACITOR 10uF 50V M
 Symbol No. Part No. Part Name Description Local
