SP-DW103
3-5
Exploded view of general Assembly and
parts list (Speaker)
Block No. [M][P][M][M]
Symbol
No.
Part No. Part Name Description Local
1 CR160063-01 SPEAKER
2 7005942502 SCREW (x14)
3 9000008701 FOOT(FRONT/R)
4 9000008711 FOOT(FRONT/L)
5 9000008801 FOOT (x2)
6 2810006601 SPACER(R)
7 2810006611 SPACER(L)
8 9916011201 BAFFLE ASSY
9 6903540001 PLANE WASHER (x8)
10 6903640001 SPRING WASHER (x8)
11 7001542501 SCREW (x8)
12 5600006901 RUBBER FOOT (x4)
To Next Page
