1-2 (No.MB515)
SPECIFICATION
Amplifier section Output Power CA-MXDK1/CA-MXDK15 90 W per channel, min. RMS, driven into 6 Ω at 1 kHz
with no more than 10% total harmonic distortion.
CA-MXDK3 MAIN SPEAKERS 100 W per channel, min. RMS, driven into 6
Ω at 1 kHz
with no more than 10% total harmonic distortion.
SUBWOOFERS 100 W per channel, min. RMS, driven into 6
Ω at 63 Hz
with no more than 10% total harmonic distortion.
Digital output OPTICAL DIGITAL OUTPUT -21 dBm to -15 dBm (660 nm ±30 nm)
Audio input sensitivity/
Impedance*1
AUX 400 mV/47 k
Ω
MIC 1/2 3.0 mV/50 k Ω
VIDEO OUT Color system NTSC/PAL selectable
VIDEO (composite) 1 V(p-p)/75
Ω
S-VIDEO Y (luminance) 1 V(p-p)/75 Ω
C (chrominance, burst) 0.286 V(p-p)/75 Ω
COMPONENT
(Interlace/Progressive:
CA-MXDK5 only)
(Y) 1 V(p-p)/75
Ω
(PB/PR) 0.7 V(p-p)/75 Ω
Speaker Terminals 6 Ω - 16 Ω (Main speakers)
6
Ω - 16 Ω (Subwoofers)
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM (MW) tuning range 531 kHz - 1 710 kHz (at 9 kHz)
530 kHz - 1 710 kHz (at 10 kHz)
531 kHz - 1 602 kHz (at 9 kHz) (For Saudi Arabia only)
530 kHz - 1 600 kHz (at 10 kHz)
Disc player section Playable disc DVD Video/DVD Audio*2/CD/VCD/SVCD
CD-R/-RW/-ROM (CD/VCD/SVCD/MP3/WMA/MPEG-
1/MPEG-2/ASF*2/JPEG/DivX*2 format)
DVD-R/-RW (DVD Video/DVD Video Recording (VR)/
MP3/WMA/MPEG-1/MPEG-2/ASF*2/JPEG/DivX*2 for-
mat)
+R/+RW (DVD Video format)
Dynamic range 90 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
Cassette deck section Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 110 V / AC 127 V / AC 220 V / AC 230 V - AC 240
V , (adjustable with the voltage selector), 50 Hz / 60 Hz
Power consumption at operation 160 W (CA-MXDK3)
95 W (CA-MXDK1/ CA-MXDK15)
on standby 20 W (CA-MXDK3)
17 W (CA-MXDK1/ CA-MXDK15)
Dimensions (approx.) 265 mm
× 337 mm × 370 mm (W/H/D)
Mass (approx.) CA-MXDK5/CA-MXDK3 8.4 kg
CA-MXDK1/CA-MXDK15 7.9 kg
