JVC SP-MXDK3F Service Manual

1-20 (No.MB515)
Step Operation Function Remarks
4 Push the MENU key of
remote control.
5 Push the MENU key of
remote control.
Display the check mode of a
frontend on FL.
Switch on the all-points light of
FL and LED.
FL display
12345678
HE KCC
HE KCC
HE KCC
1
Push 1 key (of 10KEY) of
remote control.
Starting of DISC & normal play
(Play from the started position)
2
Push 2 key (of 10KEY) of
remote control.
Arg2-3: 0
Arg4-5: WOBBLE detection result
Existence of WOBBLE
0: WOBBLE_NO_CHECK
(Un-checking.)
1: WOBBLE_PRESS_MEDIA
(Press)
2: WOBBLE_MINUS_MEDIA
(DVD-R/-RW Media)
3: WOBBLE_PLUS_MEDIA
(DVD+R/+RW Media)
********
Arg2-3: Laser current value
(a BACKUP value, actual
measurement)
Arg4-5: 0
********
3
Push 3 key (of 10KEY) of
remote control.
With no assignment
4
Push 4 key (of 10KEY) of
remote control.
CD_LD lighting & laser current
display
Arg2-3: Laser current value
(a BACKUP value, actual
measurement)
Arg4-5: 0
********
5
Push 5 key (of 10KEY) of
remote control.
DVD_LD lighting & laser current
display
Arg2-3: Laser current value
(a BACKUP value, actual
measurement)
Arg4-5: actual measurement
********
6
Push 6 key (of 10KEY) of
remote control.
DVD_SL x 1 JITTA measurement
mode
Arg2-3: Backup memory address
(0x00-0x46)
Arg4-5: The contents of a backup
memory
********
7
Push 7 key (of 10KEY) of
remote control.
The contents of a backup memory
(0x00-0x46) display (BWD)
Arg2-3: Backup memory address
(0x00-0x46)
Arg4-5: The contents of a backup
memory
********
8
Push 8 key (of 10KEY) of
remote control.
The contents of a backup memory
(0x00-0x46) display (FWD)
Arg2-3: 0
Arg4-5: Temperature sensor value
********
9
Push 9 key (of 10KEY) of
remote control.
Temperature sensor value
(AD value) display
Arg2-3: 0x00-0x06
(The measurement position in
VT501)
Arg4-5: JITTA value
********
10
Push 10 key (of 10KEY) of
remote control.
DVD-DL (Parallel , opposite),
DVD-SL
Search & JITTA measurement to
a predetermined position
Arg2-3: 0x00-0x0C
Arg4-5: 0
Arg2-3: Laser current value
(a BACKUP value, actual
measurement)
Arg4-5: JITTA value
********
11
Push 0 key (of 10KEY) of
remote control.
MONITOR output change
1: SRV_MONI_CIRC
2: SRV_MONI_SERVO
3-5: SRV_MONI_ANALOG
6-7: SRV_MONI_DRC
8-11: SRV_MONI_SERVO_JIG
12: SRV_MONI_DEFAULT
********
********
12
Push +10 key (of 10KEY)
of remote control.
Initialization of the contents of a
backup memory
CHECK
13
Push STOP key (of 10KEY)
of remote control.
Disk stop, LD-OFF
CHECK
14
Push OPEN/CLOSE key
(of 10KEY) of remote control.
Tray open/close
15
Push PLAY key (of 10KEY)
of remote control.
Play disc
Push the MENU key of
remote control.
Return to STEP2.
Cancel test mode. It cancels, even if it does by all
STEP.
Push the POWER key of
a main unit.
6
*1 Fundamentally ,the mode carries out a toggle by pushing the MENU key.
