3-14
Input board
Block No. [0][2]
R1161 QRJ146J-821X UNF C RESISTOR 820
Ω
1/4W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R1161 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1162 QRJ146J-821X UNF C RESISTOR 820
Ω
1/4W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R1162 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1163 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1180 QRZ0224-R22 EMIT RESISTOR 0.22
Ω
DK3US,
DK3UW,
DK3UG,
DK3UN
R1181 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1182 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1183 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1184 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1185 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1186 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1187 QRE141J-562Y C RESISTOR 5.6k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1188 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1189 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R1221 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1222 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1223 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1224 QRE141J-681Y C RESISTOR 680
Ω
1/4W J
R1225 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R1226 QRE141J-272Y C RESISTOR 2.7k
Ω
1/4W J
R1227 QRE141J-681Y C RESISTOR 680
Ω
1/4W J
R1295 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R2010 QRJ146J-4R7X UNF C RESISTOR 4.7
Ω
1/4W J
R2011 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R2012 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R2016 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R2017 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R2018 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
L1120 QQLZ035-R39 COIL 0.39uH
L1140 QQLZ035-R39 COIL 0.39uH
Symbol No.
Part No. Part Name Description Local
L1180 QQLZ035-R39 COIL 0.39uH
DK3US,
DK3UW,
DK3UG,
DK3UN
CN103 QGD2504C1-03Z CONNECTOR (1-3)
CN110 QGB2510J1-05 CONNECTOR B-B (1-5)
CN119 QGA3901F1-08 CONNECTOR W-B (1-8)
CN120 QGB2510J1-07 CONNECTOR B-B (1-7)
CN130 QGB2510J1-08 CONNECTOR B-B (1-8)
CN140 QGD2504C1-03Z CONNECTOR (1-3)
CN160 QGB2510K1-05 CONNECTOR B-B (1-5)
CN210 QGD2503F1-06 CONNECTOR (1-6)
DK3US,
DK3UW,
DK3UG,
DK3UN
CN250 QGA7901F2-02 CONNECTOR W-B (1-2)
EP119 QNZ0136-001Z EARTH PLATE
EP120 E409182-001SM GRAND TERMINAL
EP121 GV40327-002A IC BRD.HOLDER EP 651
FT111 QNG0003-001Z FUSE CLIP
FT112 QNG0003-001Z FUSE CLIP
FT131 QNG0003-001Z FUSE CLIP
FT132 QNG0003-001Z FUSE CLIP
FT151 QNG0003-001Z FUSE CLIP
FT152 QNG0003-001Z FUSE CLIP
FT511 QNG0003-001Z FUSE CLIP
FT512 QNG0003-001Z FUSE CLIP
FT521 QNG0003-001Z FUSE CLIP
FT522 QNG0003-001Z FUSE CLIP
FT531 QNG0003-001Z FUSE CLIP
FT532 QNG0003-001Z FUSE CLIP
FW100 QJK015-083324-E WIRE
FW150 QUM156-17DGZ4-E FLAT WIRE
DK3US,
DK3UW,
DK3UG,
DK3UN
FW160 QUM156-14DGZ4-E FLAT WIRE
FW170 QUM154-14DGZ4-E FLAT WIRE
J100 QNB0181-001 SPK.TERMINAL
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
J100 QNB0298-001 SPK.TERMINAL
DK3US,
DK3UW,
DK3UG,
DK3UN
J210 QNB0285-001 SPK TERMINAL
DK3US,
DK3UW,
DK3UG,
DK3UN
J220 QNN0420-001 SURROUND JACK
DK3US,
DK3UW,
DK3UG,
DK3UN
RY110 QSK0127-001 RELAY
DK3US,
DK3UW,
DK3UG,
DK3UN
RY120 QSK0127-001 RELAY
S500 QSW0812-001 VOLTAGE SWITCH
Symbol No.
Part No. Part Name Description Local
IC300 SN74AHCT08NS-X IC
IC305 LB1641 IC
IC325 KIA278R05PI IC
IC350 UPD78F0547GC IC
IC400 KIA4558F-X IC
DK3US,
DK3UW,
DK3UG,
DK3UN
Symbol No.
Part No. Part Name Description Local
To Next Page
