Front board
Block No. [0][3]
R5804 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5850 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5851 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5852 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R5852 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5853 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
R5854 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5855 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5856 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R5856 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R5857 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
R6000 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6001 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6002 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R6002 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R6003 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6101 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6102 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
DK1US,
DK1UW,
DK1UG,
DK1UN,
DK15UN
R6102 QRE141J-152Y C RESISTOR 1.5k
Ω 1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R6103 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6111 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6112 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R6113 QRE141J-432Y C RESISTOR 4.3k
Ω 1/4W J
DK3US,
DK3UW,
DK3UG,
DK3UN
R6700 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R6701 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R6800 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R6801 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R7000 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R7002 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R7500 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R7501 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R7502 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
CN300 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN301 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
 Symbol No. Part No. Part Name Description Local
CN302 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN303 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN306 QGF1205C2-09 CONNECTOR FFC/FPC (1-9)
CN307 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN308 QGF1210G1-07 CONNECTOR FFC/FPC (1-7)
CN309 QGB2510K1-08 CONNECTOR B-B (1-8)
CN311 QGB2510K1-07 CONNECTOR B-B (1-7)
CN312 QGD2504C1-03Z CONNECTOR (1-3)
CN313 QGD2504C1-03Z CONNECTOR (1-3)
CN314 QGD2504C1-04Z CONNECTOR (1-4)
CN330 QGA2501C1-03 CONNECTOR W-B (1-3)
DK3US,
DK3UW,
DK3UG,
DK3UN
CN335 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
HS325 LV40057-002A HEAT SINK
J3300 GP1FAV30TK0F OPT TRANSMITTER
J6700 QNN0420-001 SURROUND JACK
J7500 QNN0557-002 PIN JACK
K3000 QQR0621-001Z COIL
SC325 QYSBSG3008ZA TAP SCREW M3 x 8mm
X3500 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
IC901 PT6315 IC
IC902 GP1UM281XKVF IR DETECT UNIT
IC950 PT2399-S-W ECHO IC
IC960 KIA4558F-X IC
Q9530 KTC3875/YG/-X TRANSISTOR
Q9531 KTC3875/YG/-X TRANSISTOR
Q9532 KTC3875/YG/-X TRANSISTOR
Q9601 KTC3875/YG/-X TRANSISTOR
Q9602 KTC3875/YG/-X TRANSISTOR
D9000 SLI-343URC-W-T LED
D9200 SLI-570UT3F LED
D9201 SLR-343VC-T LED
DK3US,
DK3UW,
DK3UG,
DK3UN
D9500 MTZJ5.1B-T2 Z DIODE
D9521 MTZJ3.9B-T2 Z DIODE
D9522 MTZJ3.9B-T2 Z DIODE
D9523 MTZJ3.9B-T2 Z DIODE
D9601 1SS133-T2 SI DIODE
D9602 1SS133-T2 SI DIODE
D9653 UDZW2.4B-X Z DIODE
D9899 MTZJ2.4B-T2 Z DIODE
C9001 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9002 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C9005 NCB31HK-471X C CAPACITOR 470pF 50V K
C9091 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C9093 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9094 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C9096 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C9097 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C9200 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9401 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9500 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C9501 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C9502 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9503 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9504 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C9505 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C9506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9507 NCB31HK-561X C CAPACITOR 560pF 50V K
C9508 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9509 QEKC1CM-106Z E CAPACITOR 10uF 16V M
 Symbol No. Part No. Part Name Description Local
