JVC SP-MXDK3F Service Manual

3-21
Cassette board
Block No. [0][4]
DVD switch board
Block No. [0][5]
DVD module board
Block No. [0][6]
TW962 QUB220-18HPDM-E S.WIRE
 Symbol No. Part No. Part Name Description Local
IC200 HA12237F IC
Q110 KTA1271/OY/-T TRANSISTOR
Q111 KRC107S-X DIGI TRANSISTOR
Q120 KTA1296/Y/-T TRANSISTOR
Q121 KRC107S-X DIGI TRANSISTOR
Q150 KTA1296/Y/-T TRANSISTOR
Q151 KRC107S-X DIGI TRANSISTOR
Q200 KRA102S-X DIGI TRANSISTOR
Q201 KTC2876-T TRANSISTOR
Q202 KTC2876-T TRANSISTOR
Q203 KTC2876-T TRANSISTOR
Q204 KTC2876-T TRANSISTOR
Q205 KRC107S-X DIGI TRANSISTOR
Q206 KRC107S-X DIGI TRANSISTOR
Q300 KTC3203/OY/-T TRANSISTOR
Q301 KTC3203/OY/-T TRANSISTOR
D121 1N4003S-T5 SI DIODE
D122 1N4003S-T5 SI DIODE
D151 1N4003S-T5 SI DIODE
D152 1N4003S-T5 SI DIODE
D200 QUY150-050Y BUS WIRE
C110 QETN1HM-106Z E CAPACITOR 10uF 50V M
C122 QETN1CM-107Z E CAPACITOR 100uF 16V M
C202 NCB31HK-122X C CAPACITOR 1200pF 50V K
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 QQR1730-001 POWER INDUCTOR
C206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C209 QETN1AM-227Z E CAPACITOR 220uF 10V M
C210 QETN1HM-105Z E CAPACITOR 1uF 50V M
C211 QETN1HM-106Z E CAPACITOR 10uF 50V M
C212 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C213 QQR1730-001 POWER INDUCTOR
C214 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C216 NCB31HK-272X C CAPACITOR 2700pF 50V K
C219 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C220 QETN1HM-226Z E CAPACITOR 22uF 50V M
C221 QETN1HM-105Z E CAPACITOR 1uF 50V M
C222 QETN1HM-226Z E CAPACITOR 22uF 50V M
C223 NCB31HK-682X C CAPACITOR
C224 NCB31HK-682X C CAPACITOR
C225 NCB31HK-122X C CAPACITOR 1200pF 50V K
C226 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C227 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C228 QETN1CM-107Z E CAPACITOR 100uF 16V M
C231 NCB31HK-272X C CAPACITOR 2700pF 50V K
C232 NCB31HK-152X C CAPACITOR 1500pF 50V K
C233 NCB31HK-152X C CAPACITOR 1500pF 50V K
C300 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C301 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C303 QFG32AJ-273Z PP CAPACITOR 0.027uF 100V J
C304 QETN1CM-107Z E CAPACITOR 100uF 16V M
C306 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C307 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
R110 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R123 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R153 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R200 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R201 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R202 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R203 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
R204 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
R205 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R206 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R207 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R208 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R209 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R210 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
R211 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R213 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R214 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R215 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R216 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R218 NRSA63J-123X MG RESISTOR
R219 NRSA63J-123X MG RESISTOR
R220 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R221 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R222 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R223 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R224 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R225 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R226 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R227 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R234 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R235 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R300 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R301 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
 R302 QRZ9005-100X FUSI RESISTOR 10 Ω
R303 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R304 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R305 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
 R306 QRJ146J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R307 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R308 QRE141J-474Y C RESISTOR 470k Ω 1/4W J
VR300 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
L300 QQR1118-002 OSC COIL(BIAS)
L301 QQL244K-100Z COIL 10uH K
CN100 QGF1205F2-19 CONNECTOR FFC/FPC (1-19)
CN120 QGF1205F2-07 CONNECTOR FFC/FPC (1-7)
CN200 QGB2021L1-06 CONNECTOR B-B (1-6)
CN220 QGA2001F1-03 CONNECTOR W-B (1-3)
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1074-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0009AA IC
IC302 MM1701CH-X IC
IC305 MM1563BF-X IC 3.1V Regulator
IC453 S-80827CNNB-G-W IC
IC505 K4S641632H-UC75 IC
IC505 or K4S641632K-UC75 IC
IC509 ----------------- IC(MICRO C ROM)
IC509 or ----------------- IC(MICRO C ROM)
IC510 BR24L16F-W-X IC
IC701 AK4387ET-X IC
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
