JVC SP-MXDK3F Service Manual

3-23
R334 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R335 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R336 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R337 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30k
Ω 1/16W D
R341 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R342 NRSA63D-242X MG RESISTOR 2.4k Ω 1/16W D
R345 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R346 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R347 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R348 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R350 NRSA63J-751X MG RESISTOR 750 Ω 1/16W J
R351 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R352 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R353 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R357 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R358 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R362 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R367 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R372 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R373 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R375 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R376 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R377 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R383 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R385 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R392 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R458 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R535 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R541 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R542 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R701 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R718 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R721 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R723 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R730 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R731 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R732 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
CN101 QGF0523F3-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN701 QGF1016F8-25W CONNECTOR FFC/FPC (1-25)
CN712 QGF1016F8-05W CONNECTOR FFC/FPC (1-5)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K501 NQR0502-001X FERRITE BEADS
K701 NQR0022-002X FERRITE BEADS
K702 NQR0022-002X FERRITE BEADS
K703 NQR0022-002X FERRITE BEADS
K704 NQR0022-002X FERRITE BEADS
K705 NQR0022-002X FERRITE BEADS
K706 NQR0022-005X FERRITE BEADS
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K711 NQR0022-002X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K721 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
TH301 NAD0025-103X N THERMISTOR 10k
Ω
X301 NAX0741-001X CRYSTAL
 Symbol No. Part No. Part Name Description Local
