JVC SP-PW880 Service Manual

SP-PW880
3-5
Item Parts number Parts name Area
A
Parts list(Amp. assembly)
Q'ty Description
Block No. M2MM
1 LV10253-001A COVER 1
2 LV20470-005A BACK PANEL E,EN1
LV20470-006A BACK PANEL US1
3 LV41146-001A VOLUME BRACKET 1
4 LV41147-001A AC BRACKET 1
5 LV31303-002A HEAT SINK
A
1
6 LV41211-001A HEAT SINK
A
1
7 LV41148-001A CORD COVER 1
8 LV30225-025A SPACER 1
9 LV30225-026A SPACER 2
10 LV30225-027A SPACER 2
11 LV30225-028A SPACER 1
12 LV30225-029A SPACER 2
13 LV30225-030A SPACER 1
14 QYSBSF3008Z SCREW 5 FOR AC BRACKET
15 QYSBSF4016Z SCREW 4 FOR TRANS
16 QYWLS417610Z WASHER 4
17 QYSBSF3008Z SCREW 6 FOR PCB
18 QYSBSF3008M SCREW 3 FOR SPK TERMINA
19 QYSBST3006Z T.SCREW 4 FOR POWER SW
20 QYSBSG3016Z T.SCREW 2 FOR POWER IC
21 QYSBSF4012Z SCREW 2
22 QYSBSG3010Z T.SCREW 2
23 VKZ4001-111 WIRE HOLDER 1
24 QHS3771-108 CORD STOPPER
A
1
25 E407321-002SM PUSH BUTTON 2
26 LV30734-002A KNOB 1
27 QQT0265-003 POWER TRANS E,EN
A
1
QQT0265-004 POWER TRANS US
A
1
28 QMPK090-205-JN POWER CORD
A
1
29 QMF51E2-1R0-J1 FUSE E,EN
A
1
QMF51E2-1R6-J1 FUSE US
A
1
30 QMF51E2-1R6-J1 FUSE E,EN
A
1
QMF51E2-1R25-J1 FUSE US
A
1
31 QMF51E2-1R25-J1 FUSE US
A
1
QMF51E2-1R6-J1 FUSE E,EN
A
1
32 QMF51E2-R80-J1 FUSE US
A
1
33 WJJ0097-001A E-SI C WIRE C-C 1
34 WJJ0098-001A E-SI C WIRE C-C 1
35 QYSBSF2608M TAPPING SCREW US2
T8901
T8901
F8901
F8901
F8911
F8911
F8921
F8921
F8902
