JVC SP-PWM508 Service Manual

3-17
Front board
Block No. [0][2]
R6512 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6513 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6515 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6517 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6518 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R6601 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6602 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6603 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6604 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6605 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6606 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6607 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6608 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6609 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6610 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6611 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R6612 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6613 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6614 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6615 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6616 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6617 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6618 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7101 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7102 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7103 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7104 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7105 NRSA63J-564X MG RESISTOR 560k Ω 1/16W J
R7106 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R7107 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R7201 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7202 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7301 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R7302 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R7401 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7402 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R7403 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7404 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7601 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7602 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7603 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7604 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7605 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7606 NRSA63J-433X MG RESISTOR 43k Ω 1/16W J
R7607 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R7901 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R7902 QRE141J-471Y C RESISTOR 470
Ω 1/4W J
R7903 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R7904 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
VR701 QVQ0112-B24 V RESISTOR
 L901 QQR1105-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L952 QQL44BK-220Z COIL 22uH K
L955 QQL26AK-220Z COIL 22uH K
L957 QQL244K-100Z COIL 10uH K
L959 QQL244K-100Z COIL 10uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0097-001 SW TRANSF
CN401 QGF1036C1-10 CONNECTOR FFC/FPC (1-10)
CN402 QGF1036C1-08 CONNECTOR FFC/FPC (1-8)
CN403 QGF1036C1-28 CONNECTOR FFC/FPC (1-28)
CN404 QGD2504C1-05Z CONNECTOR (1-5)
CN405 QGD2504C1-05Z CONNECTOR (1-5)
CN406 QGD2504C1-04Z CONNECTOR (1-4)
CN407 QGD2504C1-05Z CONNECTOR (1-5)
CN410 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1036C1-31 CONNECTOR FFC/FPC (1-31)
CN412 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN450 QGF1036C1-19 CONNECTOR FFC/FPC (1-19)
CN456 QGD2504C1-03Z CONNECTOR (1-3)
CN457 QGD2504C1-03Z CONNECTOR (1-3)
CN460 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN701 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
 Symbol No. Part No. Part Name Description Local
 CP471 ICP-N5-T IC PROTECTOR 250mA
 CP951 ICP-N10-T IC PROTECTOR 400mA
 CP952 ICP-N5-T IC PROTECTOR 250mA
EP401 QNZ0136-001Z EARTH PLATE
EP402 QNZ0136-001Z EARTH PLATE
EP403 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW901 QUM219-06DGZ4 PARA RIBON WIR
FW902 QUM21A-06DGZ4 PARA RIBON WIR
HS901 E70306-002 HEAT SINK
J4401 QNN0570-001 PIN JACK
J4402 QNN0572-001 PIN JACK
J4891 QNS0089-001 3.5 JACK
J6001 QNS0170-001 HEADPHONE JACK
J7001 QNS0170-001 HEADPHONE JACK
J7002 QNS0170-001 HEADPHONE JACK
K4702 QQR0621-001Z COIL
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
K7001 NQR0007-002X FERRITE BEADS
 P901 QNC0081-001 AC INLET
PP401 QZW0112-001 WIRE CLAMP
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC501 MN101C35DKW IC(MPU)
IC511 GP1UM271XK IR DETECT UNIT 38kHz
Q501 KRC102S-X DIGI TRANSISTOR
Q502 KRC102S-X DIGI TRANSISTOR
Q503 KRC102S-X DIGI TRANSISTOR
Q551 KRC102S-X DIGI TRANSISTOR
Q552 KRC111S-X TRANSISTOR
Q561 KRA102S-X DIGI TRANSISTOR
Q562 KRA102S-X DIGI TRANSISTOR
Q563 KRA102S-X DIGI TRANSISTOR
Q564 KRA102S-X DIGI TRANSISTOR
Q565 KRA102S-X DIGI TRANSISTOR
Q566 KRC110S-X DIGI TRANSISTOR
D511 SLR-343VC-T LED
D551 SELU2E10C-P LED
D561 SML310BAT/JKL-X LED
D562 SML310BAT/JKL-X LED
D563 SML310BAT/JKL-X LED
D564 SML310BAT/JKL-X LED
D565 SML310BAT/JKL-X LED
D566 MA111-X SI DIODE
D567 MA111-X SI DIODE
D568 MA111-X SI DIODE
C501 NCB31HK-471X C CAPACITOR 470pF 50V K
C502 NCB31HK-471X C CAPACITOR 470pF 50V K
C503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C504 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C505 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB21CK-105X C CAPACITOR 1uF 16V K
C541 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R501 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R502 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
