JVC SP-PWM508 Service Manual

3-18
Audio board
Block No. [0][3]
R503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R504 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R511 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R521 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R522 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R526 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R527 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R528 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R531 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R532 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R533 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R534 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R536 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R537 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R538 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R539 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R541 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R542 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R551 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R552 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R553 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R561 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R562 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R563 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R564 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R565 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
BK501 LV43659-001A FL HOLDER
BK502 LV43659-001A FL HOLDER
CN501 QGF1016F2-19W CONNECTOR FFC/FPC (1-19)
CN551 QGF1036C1-04 CONNECTOR FFC/FPC (1-4)
CN561 QGF1005F1-04 CONNECTOR FFC/FPC (1-4)
DI501 QLF0131-002 FL TUBE
FW502 QUM214-08Z3Z3 PARA RIBON WIR
FW521 QUM213-12DGZ4 PARA RIBON WIRE
FW561 QUM213-16DGZ3 PARA RIBON WIRE
JS541 QSW1059-001 JOG VOLUME
S521 QSW0683-001Z PUSH SW
S522 QSW0683-001Z PUSH SW
S523 QSW0683-001Z PUSH SW
S526 QSW0683-001Z PUSH SW
S527 QSW0683-001Z PUSH SW
S528 QSW0683-001Z PUSH SW
S529 QSW0683-001Z PUSH SW
S531 QSW0683-001Z PUSH SW
S532 QSW0683-001Z PUSH SW
S533 QSW0683-001Z PUSH SW
S534 QSW0683-001Z PUSH SW
S535 QSW0683-001Z PUSH SW
S536 QSW0683-001Z PUSH SW
S537 QSW0683-001Z PUSH SW
S538 QSW0683-001Z PUSH SW
S539 QSW0683-001Z PUSH SW
S540 QSW0683-001Z PUSH SW
X501 NAX0623-001X C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC151 CD4066BM-X IC
IC152 CD4066BM-X IC
IC153 BD3814FV-X IC
IC158 RC4580ID-X IC
IC159 RC4580ID-X IC
IC160 RC4580ID-X IC
IC509 GP1FA352RZ OPT RECEIVER
IC510 GP1FA553TZ0F IC
IC531 RC4580ID-X IC
IC581 RC4580ID-X IC
IC591 RC4580ID-X IC
Q1131 IMX9-W TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q1133 IMX9-W TRANSISTOR
Q1135 IMX9-W TRANSISTOR
Q1137 2SC3661-X TRANSISTOR
Q1251 KRA104S-X DIGI TRANSISTOR
Q1252 KRA104S-X DIGI TRANSISTOR
C1001 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1002 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1003 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCS31HJ-331X C CAPACITOR 330pF 50V J
C1102 NCS31HJ-331X C CAPACITOR 330pF 50V J
C1103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1120 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1121 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1122 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1123 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1124 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1125 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1141 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1142 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1143 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1144 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1145 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1176 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1177 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1178 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1179 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1180 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1181 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1183 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1201 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1202 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1203 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1204 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1205 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1206 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1207 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1208 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1209 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1210 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1211 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1212 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1213 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1214 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1215 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1216 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1217 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1218 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1221 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1222 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1223 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1224 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1225 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1226 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1227 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C1228 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C1230 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1251 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1252 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1253 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1254 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2504 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2525 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2526 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2527 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2528 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2531 NCB31HK-331X C CAPACITOR 330pF 50V K
C2532 NCB31HK-331X C CAPACITOR 330pF 50V K
C2533 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2534 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2535 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2536 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2539 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2540 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2541 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2542 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
 Symbol No. Part No. Part Name Description Local
