Page #79 background imageLoading...
Page #79 background image
3-19
Main(Subwoofer) board
Block No. [0][4]
C2561 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2562 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2563 NCB31HK-271X C CAPACITOR 270pF 50V K
C2564 NCB31HK-271X C CAPACITOR 270pF 50V K
C2575 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2576 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2577 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2578 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2581 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2582 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2583 NCB31HK-271X C CAPACITOR 270pF 50V K
C2584 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2585 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2589 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2590 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2592 NCB31HK-472X C CAPACITOR 4700pF 50V K
C2594 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C2597 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2599 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2600 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2603 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2604 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2605 NCS31HJ-560X C CAPACITOR 56pF 50V J
R1101 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R1102 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R1103 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R1104 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R1105 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1106 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1107 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1108 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R1109 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R1110 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1120 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1121 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1122 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1123 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1124 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1131 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1132 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1133 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1134 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1135 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1136 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1137 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1138 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1139 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1140 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1141 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1142 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1143 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1144 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1145 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1146 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1147 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1148 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1149 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R1150 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1151 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1152 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1153 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R1154 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1155 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1156 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1157 NRSA63J-242X MG RESISTOR 2.4k
Ω
1/16W J
R1158 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1161 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1162 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1163 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1164 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1165 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1166 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1167 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1168 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1169 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R1170 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R1171 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R1172 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1173 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1174 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1175 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R1176 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R1197 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R1201 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R1202 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R1251 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1252 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1253 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1254 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R2525 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2526 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2531 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2532 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2533 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2534 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2537 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2538 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2539 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R2540 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R2541 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R2542 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R2551 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2552 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2553 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2554 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2560 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2561 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R2562 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2563 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2565 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2566 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2567 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2568 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2584 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2585 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2586 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2587 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2588 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2599 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
CN441 QGF1036C1-31 CONNECTOR FFC/FPC (1-31)
CN442 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
EP101 QNZ0136-001Z EARTH PLATE
J1101 QNN0598-001 PIN JACK
J1103 QND0118-001 DIN CONNECTOR
K1101 NQR0007-002X FERRITE BEADS
Symbol No.
Part No. Part Name Description Local
IC101 STK413-430 IC
IC102 STK412-430 POWER I.C
IC103 HA17558AF-X IC
IC104 HA17558AF-X IC
IC105 HA17558AF-X IC
IC351 MN101C427NB IC
IC352 S-80840CNNB-W IC
Q1001 KTA1046/Y/ TRANSISTOR
Q1002 KTC3875/YG/-X SI TRANSISTOR
Q1003 UN221M-X DIGI TRANSISTOR
Symbol No.
Part No. Part Name Description Local
