JVC SP-THM508F Service Manual

3-23
Subwoofer amp. board
Block No. [0][5]
R3718 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3720 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3721 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3722 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3723 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3724 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R3725 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R3726 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3727 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3728 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3729 NRSA63J-1R0X MG RESISTOR 1 Ω 1/16W J
R3730 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3731 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
 R3732 QRL01DJ-180X OMF RESISTOR 18 Ω 1W J
R3733 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3734 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
 R3735 QRK126J-220X UNF C RESISTOR 22 Ω 1/2W J
R3736 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R3737 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3738 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3740 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3741 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3742 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3743 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3745 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R3746 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R3747 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3748 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3749 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3750 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3751 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R3752 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R3753 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 R3901 QRZ9005-100X FUSI RESISTOR 10 Ω
R3902 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
 R3903 QRZ9005-100X FUSI RESISTOR 10 Ω
R3904 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
 R3905 QRZ9005-100X FUSI RESISTOR 10 Ω
R3906 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R3907 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R3908 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R3909 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
L1101 QQLZ038-R45 COIL 0.45uH
L1102 QQLZ038-R45 COIL 0.45uH
L1201 QQLZ038-R45 COIL 0.45uH
L1202 QQLZ038-R45 COIL 0.45uH
L1301 QQLZ038-R45 COIL 0.45uH
L1302 QQLZ038-R45 COIL 0.45uH
L1401 QQLZ038-R45 COIL 0.45uH
L1402 QQLZ038-R45 COIL 0.45uH
L1501 QQLZ038-R45 COIL 0.45uH
L1502 QQLZ038-R45 COIL 0.45uH
CN121 QGB2510J1-12 CONNECTOR B-B (1-12)
CN122 QGB2510J1-09 CONNECTOR B-B (1-9)
CN131 QGB2510J1-18 CONNECTOR B-B (1-18)
CN132 QGB2510J1-10 CONNECTOR B-B (1-10)
CN133 QGB1214J1-18S CONNECTOR B-B (1-18)
CN251 QGA3901F2-02 CONNECTOR W-B (1-2)
CN301 QGB2510K2-18 CONNECTOR B-B (1-18)
CN302 QGB2510K2-10 CONNECTOR B-B (1-10)
CN303 QGB1214K1-18S CONNECTOR B-B (1-18)
 CN311 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN312 QGA7901C1-04 CONNECTOR W-B (1-4)
 CN321 QGA3901C1-05 CONNECTOR W-B (1-5)
EP101 QNZ0136-001Z EARTH PLATE
EP301 QNZ0136-001Z EARTH PLATE
FC311 QNG0003-001Z FUSE CLIP
FC312 QNG0003-001Z FUSE CLIP
FC313 QNG0003-001Z FUSE CLIP
FC314 QNG0003-001Z FUSE CLIP
FC321 QNG0003-001Z FUSE CLIP
FC322 QNG0003-001Z FUSE CLIP
FC323 QNG0003-001Z FUSE CLIP
FC324 QNG0003-001Z FUSE CLIP
HS301 QZW0138-001 HEAT SINK
HS302 QZW0138-001 HEAT SINK
 Symbol No. Part No. Part Name Description Local
J1001 QND0118-001 DIN CONNECTOR
J1002 QNB0192-001 SPEAKER TERMINA
RY101 QSK0127-001 RELAY
RY102 QSK0142-001 RELAY
RY103 QSK0127-001 RELAY
 RY311 QSK0098-001 RELAY
 RY321 QSK0098-001 RELAY
 RY322 QSK0098-001 RELAY
 S3101 QSW0924-001 VOLTAGE SWITCH
TH101 QAD0146-103 N THERMISTOR 10k Ω
WC131 QZW0112-001 WIRE CLAMP
WC132 QZW0112-001 WIRE CLAMP
X3501 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC201 NJM4580M-X IC
IC202 NJM2115V-W IC
IC203 NJU7109F3-X IC
IC204 MM74HC00SJ-X IC
IC205 MM74HCU04SJ-X IC
IC211 MM74HC00SJ-X IC
IC221 MM74HC00SJ-X IC
IC271 HA17558AF-X IC
IC291 NJM78L05A-T IC
Q2001 UN2110-X DIGI TRANSISTOR
Q2002 KTC3875/YG/-X SI TRANSISTOR
Q2003 KTA1268/GL/-T TRANSISTOR
Q2004 KTA1504/YG/-X SI TRANSISTOR
Q2005 UN221M-X DIGI TRANSISTOR
Q2006 UN221M-X DIGI TRANSISTOR
Q2007 KTA1504/YG/-X SI TRANSISTOR
Q2007 KTC3875/YG/-X SI TRANSISTOR
Q2101 2SC2713/L/-X TRANSISTOR
Q2102 2SA1162/G/-X TRANSISTOR
Q2103 2SC1815/G/-T TRANSISTOR
Q2104 2SA1015/G/-T TRANSISTOR
Q2105 2SC1815/G/-T TRANSISTOR
Q2106 2SA1015/G/-T TRANSISTOR
Q2107 2SC2712/G/-X TRANSISTOR
Q2108 2SC1815/G/-T TRANSISTOR
Q2109 2SA1015/G/-T TRANSISTOR
Q2110 2SC1815/G/-T TRANSISTOR
Q2111 2SA1015/G/-T TRANSISTOR
Q2112 2SK3603-01MR POWER MOS FET
Q2113 2SK3603-01MR POWER MOS FET
Q2114 2SA1514K/RS/-X TRANSISTOR
Q2115 2SA1514K/RS/-X TRANSISTOR
Q2201 2SC2713/L/-X TRANSISTOR
Q2202 2SA1162/G/-X TRANSISTOR
Q2203 2SC1815/G/-T TRANSISTOR
Q2204 2SA1015/G/-T TRANSISTOR
Q2205 2SC1815/G/-T TRANSISTOR
Q2206 2SA1015/G/-T TRANSISTOR
Q2207 2SC2712/G/-X TRANSISTOR
Q2208 2SC1815/G/-T TRANSISTOR
Q2209 2SA1015/G/-T TRANSISTOR
Q2210 2SC1815/G/-T TRANSISTOR
Q2211 2SA1015/G/-T TRANSISTOR
Q2212 2SK3603-01MR POWER MOS FET
Q2213 2SK3603-01MR POWER MOS FET
Q2214 2SA1514K/RS/-X TRANSISTOR
Q2215 2SA1514K/RS/-X TRANSISTOR
Q2701 KTA1504/YG/-X SI TRANSISTOR
Q2702 KTC3875/YG/-X SI TRANSISTOR
Q2703 KTC3875/YG/-X SI TRANSISTOR
Q2704 UN2211-X TRANSISTOR
Q2705 UN221M-X DIGI TRANSISTOR
Q2706 KTC3875/YG/-X SI TRANSISTOR
Q2707 UN2211-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
